Specifications
1.Hot Filling Machine2.Materials: stainless steel
3.Production:2000~24000 BPH
bottled water filling machine
Washing, filling and capping machine
It is an automatic washing, filling and capping three in one machine. PLC of this machine is adopted OMRON brand made in Japan, All electrical parts are adopted Siemens brand, proximity switches adopt AUTHORNIC brand.
(1) External dimensions: 3600×2800×2650 mm
(2) Weight: 8T
(3) Washing heads:32
(4) Filling heads:32
(5) Capping heads:10
(6) Production capacity: 15000bph at 500ml bottle
(7) The parts contract with the liquid is adopted SUS304 stainless steel
(8) Total power: 8.07KW
(9) Filling material: water
(10) Conveyor form: air conveyor
(11) Bottle application: plastic PET
Diameter of bottle body: Φ50mmΦ100mm
Height: 150mm-320mm
Maximum of cap: Φ25-Φ40mm
Lid application: plastic
Adjustable form: transducer
(12) Volume of bottle: 330ml-2.5L
(13) Power of lid unscramble:0.37KW
Hot Filling Machine
| Main Technical parameters | ||||||||
| Model | CGFR 16126 |
CGFR 18186 |
CGFR 24248 |
CGFR 32328 |
CGFR 404010 |
CGFR 484812 |
CGFR 606015 |
CGFR 808020 |
| Heads of washing, filling, sealing | 16-12-6 | 18-18-6 | 24-24-8 | 32-32-8 | 40-40-10 | 48-48-12 | 60-60-15 | 80-80-20 |
| Production capacity(bottle/hour) | 3000-4000 | 5000-7000 | 8000-12000 | 12000-15000 | 16000-18000 | 20000-24000 | 24000-28000 | 36000-40000 |
| Suitable bottle height | H=170-320 | Φ=50-100 (330-1500ml) |
||||||
| Spraying pressure | 0.25-0.3 | |||||||
| Total Power | 1.5+0.37 | 2.2+0.37 | 3+0.45+ 0.25 |
5.5 | 7.5 | 11 | 15 | 19 |
| Overall dimension(L×W×H) | 2300× 1680× 2650 |
2500× 1760× 2650 |
3100× 2100× 2650 |
3800× 2800× 2650 |
4000× 3300× 3400 |
4850× 3650× 3300 |
6500× 5400× 3500 |
7650× 6400× 2700 |
| Weight | 2600 | 3500 | 4650 | 6800 | 8500 | 1000 | 12500 | 16000 |
