Brushless AC generator 184 series is available in single or double bearing applications,self-excited Automatic Voltage Regulator,adaption adapters offered to SAE 2,3,4,5 and 6.We have in stock with very competitive pricing and best lead times.Please double check with us,we could offer exactly shipping cost for you.In order to make the business simple,quickly ,convenient for you.We could offer competitive price for shipping with any purchase of a Farrand AC generator end from us.
Purchasing a FLD 184 Series from us will include the following specification at no additional cost:
· 4 Poles
· Single Phase or three phase
· power factor 0.8 or 1.0
· 1800rpm
· 60hz
· Available voltage from 110V 220V
· 4 lead alternator
· Class H insulation
· IP23 enclosure
· High efficiency
· SX440 Automatic Voltage Regulator
· MX341 Automatic Voltage Regulator with PMG
Below you will find all the specific models associated with the FLD184 series.If you have any questions or need pricing please contact us.
For 3 Phase 4 Pole alternators
| Place of Origin | WUXI CHINA | Brand Name | FARRAND | Model Number | FLD184H |
| Output Type | AC Three Phase | Speed | 1500rpm | Frequency | 50hz |
| Rated Power | 30 kw/37.5kva | Rated Voltage | 110V-690V | Warranty | 12 MONTHS |
| Color | As your request | Label service | available | OEM series | available |
| Wire pitch | 2/3 pitch design | Pretection class | IP23 | Insulation class | H |
| Tem raise | 180 degree | Material | 100% copper wire | ||
Features:
1. Optional permanent magnetic alternator , provide invariable excitation in any situation.
2. Easy to be connected with power network or other alternators. Standard 2/3pitch windings avoid excessive neutral current.
3. Dynamically balanced rotors, with single or two sealed ball bearings.
4. Simple installation and maintenance with easy access to terminals, rotating diodes and coupling bolts.
5. Wide range of flange adaptor and single bearing coupling disc.
6.Built to conform to all leading industrial standards.
Electrical Character:
Excitation system:The main stator supplies power to exciter stator via Automatic Voltage Regulator (AVR) .The output of exciter rotor is fed to the main rotor through a three phase full wave rectifier. There are varistors at the both ends of the rectifier for restraining surge voltage and avoiding the impact caused by short circuit or parallel synchronization loss.
Exciter stator is equipped with permanent magnetic steel in order to start up the alternator smoothly in any occasion.
Insulation/Immersion
Insulation class H
All wound components are made up with specialized material and immersed in varnish by especially technology. Resin matrix material is developed to strengthen the process and machinery intensity of windings and revolving parts for the alternator working under harsh environment.
Windings and electric features
Standard 2/3 pitch windings design can eliminate the triple frequency harmonics on the voltage waveform which is the optimum design for trouble-free supply of non-linear loads.
Connected with the network in parallel, the structure can restrain excessive currents in the midline. A fully damp winding reduces oscillations during paralleling. This winding, with 2/3pitch and carefully selected pole and tooth designs, ensures very low waveform distortion.
Wiring terminal and terminal box
Standard alternator is 3 phase re-connectable to 12 ends brought out to the terminals, which are mounted on a cover at the non-drive end of the alternator .A sheet steel terminal box contains the AVR and provides ample space for customer’s wiring and gland arrangements. It has removable panel easy access.
Competitive Advantage:
- Brushless Alternator 100% copper wire
- Brushless Alternator Strict quality control system
- Brushless Alternator Competitive price
- Brushless Alternator Good Service
We have strict quality system,choose us ,not only your good supplier,but also your good friends!
Jiangsu Farrand Generator Technology Co.,Ltd is a professional large-scale manufacturer of all types of alternator,integrating development and production together.Our main products include alternators from 6.5kw(8kva) to 1000kw(1250kva), voltage from 110V to 480v, silent type,single or three phase,synchronous brushless. All interface according to international standard, matching all generators in the world. Such as Cummins, deutz, MTU, perkins, Volvo .
Farrand Generator company Located near Shanghai, we enjoy convenient water, land and air transportation. It covers an area of more than 5000m2. we have good cooperation technical and produce team.Our motto “The quality of products is the company’s life”With the motto,we make concerted efforts. Farrand carry out high standard technical regulation, techniques, strict quality inspection and mature quality guarantee system in order to manufacture world-class high quality motors.
FAQ
Q. How much will the shipping of my order cost?
Our shipping costs are calculated depending on the total weight and measurement CBM of the items you wish to purchase and your destination.We always do our best to keep the shipping costs to a minimum.Our forwarder has a long contract with us,we can get a big discount for you.
Q.How long does a sample takes?
A. If we have in stock,a sample will be delivered less than 3days.
Usually a sample takes 5 days.Please contact us which type that you needs,we will show you delivery time immediately.
Q.What is the MOQ of the product?
A.Our MOQ can meets your promotional business very well.
Q.Do you accept OEM?
A.Yes,we do.We can match any your samples.
Q.What is the level of ingress protection?
A.Ingress protection 22 standard,IP23 can be choosed.
Q.How many types of AVR do you have?
A.Such as SX460,MX321,MX341,SX440,SX440T,AS440,etc.
Q.How long is your quality guarantee period?
A.All alternators are warranted for 12 months from the notify date of waiting transportation.
