Specifications
1.mc4 Solar Pane connector2.Cable Approx.Odmm:6.3mm
3.Simple , quick , safe and effective field assembly.
4Rated Current:55A
Solar Panel Cable for MC4 Solar Panel connectors and MC3
Model: CA-040
4.9USD/Meter
250 meter/Roll
Applications:
1. Solar Panel Cable for MC4 Solar Panel connectors and MC3
Main Technical Specification:
Sepcial Type:PV1-F 1*4.00mm2
Rated Voltage:AC0.6/1kV;DC1.8kV
Nominal Cross-sectional Area :4.0mm2
Rated Current :55A
Cable Approx.Odmm:6.3mm
Main Special
Tempeature range of application -40 degree up to 90 degree ,max.tempeature at conductor 120 degree
The permiited short-circult-tempeature refer to a period of 5S is 200 degree.
High resisitance against UV ,ozone and hydrolysis.
Very high machanical robustness and resistence against water ,oil and chemicals.
It is approvalled by TUV.
Notes: This product insulation ,sheath color are black ,also we can have other colors from customers' requires
