lte yagi antenna
Features:
all weather Anodized Aluminum construction
Solid Aluminum elements
Heavy duty mounting hardware
UV-stable, UL flame rated radome
Light weight, & includes tilt and swivel mast mount
Can be installed for either vertical or horizontal polarization
Applications:
Sprint 4G WiMax
IEEE 802.16 and 802.20
WiMAX Technology
Non-Direct Line of Sight (NLOS)
Wireless Internet Service Providers (WISP)
2.4-2.6 GHz MMDS Band
Electrical Specifications | |
Model | AC-D2500Y14-12 |
Frequency Range | 2400-2600 MHz |
Band width | 200 MHz |
Gain | 14 dBi |
V.S.W.R | <1.5 |
Radiation | Direction |
Horizontal Beam width | 38° |
Vertical Beam width | 30° |
Front to back radio | >15dB |
Polarization | Vertical or horizontal |
Lightning Protection | DC ground |
Maximum Input Power | 100W |
Impedance | 50ohm |
Operating Temperature | -40℃ to+70℃ |
Connector | N female |
Cable Length | 30cm |
Mount way | Pole |
Mechanical Specifications | |
Antenna Dimension | 520*70*45mm |
Weight | 0.85KG |
Rated Wind Velocity | 60m/s |
Memo: Above specification subject to change without further notice.Please contact us for more details.
