PV Solar Junction Box for Low Power PV Module /80-110watt Solar Mc4 Solar Connectors

PV Solar Junction Box for Low Power PV Module /80-110watt Solar Mc4 Solar Connectors thumbnail-1
PV Solar Junction Box for Low Power PV Module /80-110watt Solar Mc4 Solar Connectors photo-1
US$ 5.58 - 7.65 MOQ: 100 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Superbat
Model Number:
PV-2124-JB018-3
Contact Supplier Request Quote Chat Now
Shenzhen Superbat Electronics Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name Superbat
Model Number PV-2124-JB018-3
Type Other, PV Junction Box

Specifications

1.mc4 solar connectors
2.Rated Voltage:1000V
3.Diodes Details:2PCS
4.Overall dimensions:105*80*25mm
5.Rated Current:7A



PV Solar Junction Box for Low power PV module /80-110watt solar # C01



Model: PV-2124-JB018-3





The Solar Junction Box, designed for robotic-assembly of silicon photovoltaic systems, reduces assembly time and production costs for PV-panel manufacturers. Rugged and durable, IP67-sealed, DC connectors feature simple snap-lock mating and an internal locking mechanism for superior safety. They are designed for direct connection to solar junction boxes, field installations and PV grid wiring. In addition, DC double-insulated cable assemblies, with proven long life cycle and optimum weather resistance, meet the demands of harsh and outdoor solar wiring applications.



Main technical parameters

Current for PV Module 7A
Rated Voltage DC 1000V
Protection Degree IP65
Power Capacity 80-110W Solar panel
Touch Protection Class Ⅱ
Temperature Range -40°C ~ 85°C
Diodes Details 2 pcs
Number of terminals 3 rails
Wire Size 4mm2 (~10 gauge AWG)
Contact Resistance <5Ohm
Flame Class UL94-V0
Contact Material Copper
Insulation Material PPO
Overall dimensions 105*80*25mm
N.W(KG) 0.090KG



Product Features:

1.With the capacity of anti-aging and UV resistant, provide longer life span under outdoor bad condition.
2.Adopted reliable connection solution ,simple,quick and safe effective field assembly.
3.Designed Specially for 50watt to 150watt solar panel,used widely in solar street lights,solar lawn lights etc.
4.Adopted welding and crimping connect way,easy,quick and reliable







PV Solar Junction Box for Low power PV module /80-110watt solar mc4 solar connectors



PV Solar Junction Box for Low power PV module /80-110watt solar mc4 solar connectors



PV Solar Junction Box for Low power PV module /80-110watt solar mc4 solar connectors



Easy-Using & Cheap! Don't Hesitate~! Just take it~!







Please note these information





PV Solar Junction Box for Low power PV module /80-110watt solar mc4 solar connectors
