2.4GHz Fiberglass Car Magnetic Waterpoof Antenna for Outdoor Solution

Specifications

2.4GHz fiberglass car magnetic waterpoof antenna for outdoor solution 1.Freq:2400-2483MHz
2.Gain:7dBi
3.Size:110*660mm

2.4GHz fiberglass car magnetic waterpoof antenna for outdoor solution











Applications:
2.4GHz-2.5GHz ISM Band
IEEE 802.11b, 802.11g, 802.11n Wireless LAN
Directional and multipoint applications
Bluetooth,WiFi, RFID
Public Wireless Hotspot
Wireless Video Systems

Features :
Superior Performance
The Weight is light
Good appearance designs
Installed for vertical or horizontal polarization
Outdoor antenna for public Hot spots
Heavy Duty mounting
RoHS Compliant
To increase the range and reliability of wireless links
antennas also feature rugged,
weatherized construction making them well suited for
both indoor and outdoor applications
The antenna includes complete mounting hardware for standard masts





Electrical Specifications
Model	AC-Q24I26
Frequency Range	2400-2483MHz
Band width	83MHz
Gain	7dBi
V.S.W.R	≤2.0
Radiation	Omni
Polarization	Vertical
Maximum Input Power	50W
Impedance	50ohm
Operating Temperature	-40℃ to+70℃
Connector	SMA Male
Cable type	RG58U
Cable Length	3m
Mechanical Specifications
Antenna Dimension	Φ110×660mm
Weight	1.18Kg
