2.4G WIFI PCB internal antenna
- 2147483647 Piece / Pieces per Month
- foshan
- Credit Card
Product Details
Place of Origin: | Guangdong, China | Brand Name: | AC | Model Number: | AC-Q24-N05 |
Packaging Details
100pcs per bag
Product Description
Specifications
2.4G WIFI PCB internal antenna1.Freq:2400-2500MHz
2.Gain:2.5dBi
3.Size:22*115mm
2.4G WIFI PCB internal antenna
Applications:
for 2. 4ghz spread spectrum of communications
Mobile terminal design of the secondary benefits
of antenna and antenna body. the special pcb board
is in great shape for installing.
Features:
antenna for 2. 4g system of communication
terminals.the antenna design of the production
structure and beauty for installing.
Electrical Specifications | |
Model | AC-Q24N05 |
Frequency Range | 2400-2483MHz |
Gain | 2.5dBi |
VSWR | ≤1.5 |
Polarization | Vertical |
Impedance | 50ohm |
Maximum Input Power | 50W |
Connector | SMA Male |
Operating Temperature | -40°C to+80°C |
Mechanical Specifications | |
Cable length(mm) | 100/200 etc |
Cable type | RG174 |
Antenna Dimension | 22×115mm |
Weight | 10g |
Company Profile
Asian Creation Communication co.,Ltd is a Professional Antenna Manufacturer in China, established in 2001. Based on a 5000 square metre site, Asian Creation have 110 employees ,now we has 6 engineers, 5 senior technicians and a regular company structure.
Asian Creation Communication Equipment Factory is a hi-tech enterprise specialized in the development and production of communication antennas; our leading portfolio are the high quality antenna products, including wlan antenna, wifi antenna, wimax antenna, wireless antenna, MIMO antenna, UHF/VHF antenna, GSM/UMTS/AMPS antenna, 2.4GHz antenna, 5.8GHz antenna, LTE antenna, 3G antenna, DVB antenna, GPS antenna, RFID antenna, etc.. We also supply a full range of antenna components: power splitters, couplers, surge protectors, router enclosure etc.
To guarantee the quality and deliver time,our company have 8 production lines and uses advanced testing equipment, such as HP87 network analyzer, frequency spectrum analyzer, standard microwave anechoic chamber, antenna near field-testing After 5 years of development, our existing distributors located in the United States, Lebanon, Israel, Germany, Italy.etc. . System and far field automatic testing systems amongst other standard testing equipments.
Our manufacturing standards of wlan antenna, wifi antenna and wimax antenna conform to ISO9001:2000. The strong growth of our wlan antenna, wifi antenna and wimax antenna products in the communication area demonstrate our commitment to strict quality management standards, first class equipment performance professionals providing technical support and efficient after services to all our customers.
