Manual Insertion Type Reader for Mobile Payment Point of Sale-MP506-33

US$ 38 - 42 MOQ: 10 Units

Key Specifications

Brand Name:

HCC

Model Number:

Manual insertion type reader for Mobile payment point of sale-MP506-33

Type:

CF Card, Memory Stick Card, MMC Card, SD Card, SM Card, XD Card

Shenzhen HCC Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHENZHEN GUANZGHOU HONGKONG

Delivery Detail:

Delivery time depends on order quantity.

Brand Name HCC

Model Number Manual insertion type reader for Mobile payment point of sale-MP506-33

Type CF Card, Memory Stick Card, MMC Card, SD Card, SM Card, XD Card

Interface ExpressCard slot

Card Slots All in 1 / Multi in 1

Installation External

Place of Origin Guangdong, China

Manual insertion type reader for Mobile payment point of sale-MP506-33

Feature

1. Manual insertion type reader

2. ISO 7810 ~ 7813 triple track conformance

3. ISO7816 compliance

4. EMV Contact L1 and L2 certification

5. 12 keys pad made of high quality film

6. Support 3DES encryption and DUKPT key management

7. Audio jack, Bluetooth and USB interface

8. Power by rechargeable Li Ion battery through Mini USB socket

9. With a buzzer and 3 LED for battery indicator

10. Very compact size

Specification

Items		Contents
ISO 7810 ~ 7813	Track	Track 1	Track 2	Track 3
	Recording density	210 BPI	75BPI	210 BPI
	Capacity	79 characters (7 bit code)	40 characters (5 bit code)	107 characters (5 bit code)
	Start / End Code	% / ?	; / ?	; / ?
Smart Card		ISO7816 T=0/T=1, EMV2000 L1/L2, PBOC3.0 L1/L2
PIN Pad & Encryption		1. 12 Key( 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, [Enter], [Cancel]) 2. Transmit PIN to Phone with 3DES encryption
Life time of ICC adaptor		Approx 200,000 times of insertion
Life time of Magnetic head		500,000 Passes Life
Power Input		Operating 3.3V DC, MAX. 55mA
Rechargeable Li Ion Battery		3.7V/160mAh, 1 hours per charge, Support 360 times of usage if 30 seconds per transaction.
Interface		1. Audio, 4 signal contacts left earphone, right earphone, ground and microphone 2. Mini USB, Virtual COM (for update parameter used) 3. Bluetooth, BT2.1+EDR and BLE
Operating System & SDK support		iOS, Android, Windows
Dimension		40 x 60 x 14.3 mm
