Rfid 13.56mhz/smart Card Reader Sam Slot/chip Card Reader Writer Software- ACR1251

US$ 32 - 40 MOQ: 1 Unit

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

ACS

Model Number:

13.56mhz/smart card reader sam slot/chip card reader- ACR1251

Shenzhen HCC Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen/Hong Kong/Guangzhou

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name ACS

Model Number 13.56mhz/smart card reader sam slot/chip card reader- ACR1251

rfid 13.56mhz/smart card reader sam slot/chip card reader writer software- ACR1251

Features

Ÿ Read/Write speed of up to 424 kbps

Ÿ Built-in antenna for contactless tag access, with card reading distance of up to 50 mm (depending on tag type)

Ÿ Supports ISO 14443 Type A and B cards, , FeliCa, and all 4 types of NFC (ISO/IEC 18092) tags

Ÿ Supports 7-byte UID, Plus and DESFire

Ÿ Built-in anti-collision feature (only one tag is accessed at any time)

Ÿ One ISO 7816 compliant SAM slot

Ÿ Supports PC/SC

Ÿ Supports CT-API (through wrapper on top of PC/SC)

Ÿ User-controllable bi-color LED

Ÿ User-controllable buzzer

Ÿ SAM Slot

Application

Specifications

Dimensions	98 mm (L) x 65 mm (W) x 12.8 mm (H)
Weight	73g
Interface	USB Full Speed
Operating Distance	Up to 50 mm (depends on the tag type)
Supply Voltage	Regulated 5V DC
Supply Current	200mA (operating)
Operating Temperature	0-50°C
Operating Frequency	13.56 MHz
Smart Card Interface Support	ISO14443 Type A & B FeliCa 4 types of NFC (ISO/IEC18092) tags
Compliance / Certifications	ISO 14443, ISO 18092, ISO 7816, LASCOM, CE, FCC, VCCI, PC/SC, CCID, RoHS, USB Full Speed Microsoft WHQL: Windows 2000, XP, Vista, 7, 8
Operating System Support	Win 98, Win ME, Win 2000, Win XP, Win Vista, Win 7, Win 8, Win Server 2003, Win Server 2003 R2, Win Server 2008 Win XP x64, Win Vista x64, Win 7 x64, Win 8 x64, Win Server 2003 x64, Win Server 2003 R2 x64, Win Server 2008 x64, Win Server 2008 R2 x64, Win Server 2012 x64 Linux Mac Android 3.1 and above
