Small USB/Wifi/bluetooth Dot-Matrix mini A4 Paper Size printer --HCT 120MP
Introduction
HCT Portable Dot Matrix Printer is one of the smallest printers in the market, designed especially for printing needs of mobile business in banking, insurance and administrative application environments.
The printer mounts a foldable paper tray both for insertion and ejection of paper. With 9 needles dot matrix technology, it can handle single sheet or multiple copies up to A4 size with the maximum thickness of 0.2mm at the printing speed of 242cps.
The printer offers a wide variety of connectivity to other HCTproducts, including Signature Pad, Card Reader, Information Interactive Terminals, and PIN Pad and so on, which greatly contributes expanding its range of applications and delivering convenience for users.
Features
Elegant and compact design.
Low cost of ownership.
Flexible in mobile business.
High reliability with MTBF>10000 hours.
Multiple copies (1 original+2 copies) handling.
Consistent performance of 24 hours standby.
Long ribbon life of 7 million characters.
Rich interfaces including Bluetooth, USB2.0 and Wifi.
Technical Specifications
Technology |
9 needles dot matrix |
|||
Printing Mode |
Bi-directional printing |
|||
Printing Width |
210mm, 138CPL (16.8CPI) |
|||
Printing Speed |
Printing Speed |
242 characters/sec(En:16.8CPI) |
||
|
Average Printing Speed |
4PPM(1/6’’line spacing, 20% print coverage) |
||
Resolution |
Maximum 168*144DPI |
|||
Paper Feeding Speed |
Maximum 100mm/sec |
|||
Emulation |
HCT/MPX |
|||
Character Fonts |
Fonts |
Chinese |
GB18030 Chinese fonts |
|
English |
96ASCII characters, 10 international code pages. Available customization according to the requirements of clients |
|||
Font type |
Chinese |
15*16, standard Chinese |
||
English |
IBM character setsⅡ, 5*7, 7*7 |
|||
Documents |
Paper width |
210mm±0.5mm |
||
Thickness |
Single sheet 0.06~0.085mm, total up to 0.2mm |
|||
Copies |
1 original +2 copies |
|||
Interface |
Standard |
USB2.0 interface |
||
Option |
Bluetooth, Wifi |
|||
Buffer |
8k |
|||
Ribbon |
HCT ribbons: NTS-210, black, 7 million characters |
|||
Reliability |
MTBF>10000 hours |
|||
Print Head Life |
300 million dots/needle |
|||
Battery |
Rechargeable lithium battery,29.6V,2200mAH |
|||
Standby Time |
24 hours |
|||
Continuous Printing Time |
an hour (10% dots coverage) |
|||
Environment |
Operating temperature:5~45℃,Humidity:10%~90%RH(no condensation) |
|||
Operating System |
Support Windows XP/Vista/7/8, Android 4.0 |
|||
Voltage |
220V±10%, 50~60Hz |
|||
Dimensions |
(W)335*(D)115*(H)112mm |
|||
Weight |
2.5KG |
|||
Notes
Print Coverage:Ratio of actual printing against the full page printing.
Dots Coverage:Ratio of actual printing dots against full page black dots.
