ACS Protable Android PC Access Smart Card Reader Writer for Loyalty--ACR38U-N1

Name: ACS Protable Android PC Access Smart Card Reader Writer for Loyalty--ACR38U-N1
Brand: ACS access card reader writer
SKU: 121430965

US$ 9 - 13 MOQ: 1 Unit

Key Specifications

Brand Name:

ACS access card reader writer

Model Number:

ACR38U-N1access card reader writer

Type:

CF Card, Memory Stick Card, MMC Card, SD Card, SM Card, XD Card

Shenzhen HCC Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHENZHEN GUANGZHOU HONGKONG SHANGHAI

Delivery Detail:

Delivery time depends on order quantity.

Brand Name ACS access card reader writer

Model Number ACR38U-N1access card reader writer

Type CF Card, Memory Stick Card, MMC Card, SD Card, SM Card, XD Card

Interface USB

Card Slots All in 1 / Multi in 1

Installation External

Place of Origin Guangdong, China

ACS Protable Android PC access Smart Card Reader Writer for Loyalty--ACR38U-N1

Feature

Read and write all microprocessor cards with T=0 or T=1 protocols
Support SLE 4418/28/32/42 memory cards
Support most common memory-based smart cards, including I2C bus protocol cards (from 1k bits up to 1024k bits) and secure memory cards (Atmel AT88SC153 and AT88SC1608)
Support 1.8V, 3V and 5V MCU cards
Short Circuit Protection
Certificate of conformance: ISO 7816-1/2/3, PC/SC, CE, FCC, Microsoft WHQL, EMV certified
Support PPS (Protocol and Parameters Selection) with 1743 – 307200 bps in reading and writing smart cards
768 bytes RAM size and 16K bytes ROM size
Extra SAM slot is optional

Application

Specification

Universal Serial Bus Interface
Type	USB full speed, four lines: +5V, GND, D+ and D-
Power source	From USB
Speed	12 Mbps
Smart Card Interface
Standard	ISO 7816 1/2/3, T=0 and T=1
Supply current	max. 50mA
Smart card read / write speed	1743 – 307200 bps
Short circuit protection	+5V / GND on all pins
The presence of the smart card power supply voltage is indicated through a green LED on the reader
CLK frequency	4 MHz
Card connector	Contact
Card insertion cycles	min. 100,000
(Optional) SAM Card Interface
Card connector	Landing
Location	Under the removable dark lid
Case
Dimensions	97mm (L) x 72mm (B) x 18.5mm (H)
Color	Golden
Operating Conditions
Temperature	0 - 50° C
Humidity	40% - 80%
Standard/Certifications	EMV Level 1, ISO7816-1/2/3, PC/SC, CE, FCC, Microsoft WHQL ME, 2K, XP
OS	Windows 98, ME, 2K, XP
OEM	OEM-Logo possible, customer-specific colors, casing, and card connector
