PRODUCT NAME : STAINLESS STEEL BAR , HEAT RESISTING STEEL BAR .( forged / rolled )
STANDARD:
GB/T1220-2007 GB/T1221-2007
GB/T20878-2007 ASTM A959-04 ISO4955:2005 ISO683-13 ISO683-16 EN10088:1-1995 EN10095-1999
GRADE COMPARISION:
GB |
ASTM |
BS |
JIS |
DIN |
06Cr17Ni12Mo2 |
316 |
X5CrNiMo17-12-2 |
SUS316 |
1.4401 |
ULTRASONIC STANDARD:
GB/T6402-2008 / SEP921-84. ASTM A388
CHEMICAL COMPOSITION:
C≤ |
Si≤ |
Mn≤ |
P≤ |
S≤ |
Cr |
Mo |
Ni |
0.08 |
1.00 |
2.00 |
0.045 |
0.030 |
16.00/18.00 |
2.00/3.00 |
10.00/14.00 |
HEAT TREATMENT SPECIFICATION AND MECHANICAL PROPERTIES:
Austenite structure.
Tensile strength ≥520
Yeild strength :(N/mm2)≥205
Elongation (%)≥40
Reduction of area :ψ (%):≥60
Hadness HB ≤187HB;≤90HRB;≤200HV
Solid solution 1010-1150℃ rapid cooling.
MANUFACTURING TECHNIQUE:
EAF+AOD+LF furnace+forged/ rolled
DELIVERY CONDITION :ANNEALED / SOLID SOLUTION
SURFACE : BLACK / GRINDING / PEELING
DIMENSION : mm
Forged round bar :dia 80-350mm
Rolled round bar :dia 8-200mm
Coild rod : dia 5.5-20mm
Wire : dia 0.2-13mm
Rolled flat bar :thickness 5-90× width 44-300mm
Forged flat bar:thickness 120-800×width 120-800
length : forged bar free length 3-5.8M,rolled bar 5.8M. for customers special requirment, the bar length can do 20 meters long.
Tolerance on diameter of forged bar : black surface -0/+5mm, peeled surface -0/+3mm.
REMARK:
Above listed parameters and sepcification only for reference . Specific parameters according to standard. Requirments beyond standard will be negotiate by both sides .
Delivery state:normalized ,annealed, spheroidal annealed, quenched & tempered ,bright bar, cold-drawn, etc. Should be indicated in contract .
Listed specifications are only typical grades; products of required specifications can be developed/produced per international, Chinese or industry standards, or based on agreements with customers.
Packing :
Forged bar , rolled bar and coil packing in loose . Rolled wire packing in plastic woven cloth or wooden case.
