Steel Wire Braided Steam Hose Q/HYT03-S

FOB Price

US$ 0.5 - 9.5 / Meter

150 Meters(Min. Order)

Port Tianjin
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Hebei, China		Brand Name	Sufeite
Model Number	Q/HYT03-S

Product Description

Product Description

Construction: Made of excellent heat-resistant rubber, The reinforcement is braided with facing wire.

Application: For conveying saturated steam and superheated water continually at a temperature below 150℃ or intermittently at a temperature below 160℃.

W/B	Hose I.D		Hose O.D.	Working Pressure		Burst Pressure		Minimum Bend Radius	Length
W/B	DN	inch	mm	MPa	Psi	MPa	Psi	mm	metres
1W	10	3/8	21.5	1.0	150	4.0	570	130	20/ 50
	13	1/2	24.5	1.0	150	4.0	570	180	20/ 50
	16	5/8	27.5	1.0	150	4.0	570	205	20/ 50
	19	3/4	30.5	1.0	150	4.0	570	240	20/ 50
	22	7/8	33.5	1.0	150	4.0	570	280	20/ 50
	25	1	37.0	1.0	150	4.0	570	300	20/ 50
	32	1 1/4	44.0	1.0	150	4.0	570	420	20/ 40
	38	1 1/2	50.5	1.0	150	4.0	570	500	20/ 40
	45	1 3/4	57.5	1.0	150	4.0	570	500	20/ 40
	51	2	63.5	1.0	150	4.0	570	630	20/ 40
	64	2 1/2	77.5	1.0	150	4.0	570	700	20/ 40
2W	10	3/8	23.0	2.0	300	6.0	860	130	20/ 50
	13	1/2	26.0	2.0	300	6.0	860	180	20/ 50
	16	5/8	29.0	2.0	300	6.0	860	205	20/ 50
	19	3/4	32.0	2.0	300	6.0	860	240	20/ 50
	22	7/8	35.0	2.0	300	6.0	860	280	20/ 50
	25	1	38.5	2.0	300	6.0	860	300	20/ 50
	32	1 1/4	45.5	2.0	300	6.0	860	420	20/ 40
	38	1 1/2	52.0	2.0	300	6.0	860	500	20/ 40
	45	1 3/4	59.0	2.0	300	6.0	860	500	20/ 40
	51	2	65.0	2.0	300	6.0	860	630	20/ 40
	64	2 1/2	79.0	2.0	300	6.0	860	700	20/ 40

Company Information

The company has domestic and foreign advanced equipment and technology, strong sales and service team. The company can produce high pressure and ultra high pressure hose and assembly, the flame retardant and antistatic hose, engineering machinery hydraulic hose, temperature and cold resistant rubber hose, gas drainage hose, marine high pressure oil tube, oil drilling hose, various specifications of stainless steel bellows, metal hose, PTEE pipe. The company’s products throughout the country, and exported to Europe and the United States, the Middle East, South America and other countries, and long-term commitment to the OEM of big company production. productions are widely used in mining, petroleum, engineering machinery field, users get the praise.
