Home > Products > New Products > Alibaba china supplier API Spec high pressure drilling rubber hose
Alibaba china supplier API Spec high pressure drilling rubber hose
- 1000000 Meter / Meters per Month
- tianjin
- T/T L/C D/P D/A Credit Card PayPal
Product Details
| Place of Origin: | Hebei, China | Brand Name: | Sufeite | Model Number: | 1/4-3'' |
Product Description
Drill Pipe Feature:
A. High precision in size and shape
B. Good low temperature toughness
C. Excellent comprehensive mechanical properties
D. High connection strength and sealability
E. Large inside diameter of tool joint
F. High torque resistanca
G. High fatigue strength and long fatigue life
Detail Mechanical Property of the Drill Pipe:
Second technical performance index
| Hose code | ID mm | OD mm | Winding layer ID mm | WP MPa | BP MPa | Bend Radius mm | Weight kg/m |
Number*ID*WP MPa | |||||||
| 2SP-51-15 | 51±1.0 | 66±1.5 | 60.8±1.0 | 15 | 60 | 850 | 5.0 |
| 4SP-51-35 | 51±1.0 | 69±1.5 | 63.8±1.0 | 35 | 70 | 900 | 5.7 |
| 2SP-64-15 | 64±1.2 | 82±1.5 | 75±1.0 | 15 | 60 | 1000 | 5.7 |
| 2SP-76-15 | 76±1.4 | 99±2.0 | 92±2.0 | 15 | 60 | 1100 | 8.5 |
| 2SP-89-15 | 89±1.4 | 114±2.0 | 107±2.0 | 15 | 60 | 1200 | 9.5 |
| 2SP-102-15 | 102±1.5 | 126±2.0 | 119±2.0 | 15 | 60 | 1300 | 12 |
Four technical performance index
| Hose code | ID mm | OD mm | Winding layer ID mm | WP MPa | BP MPa | Bend Radius mm | Weight kg/m |
Number*ID*WP MPa | |||||||
| 4SP-51-35 | 51±1.0 | 69±1.5 | 63.8±1.0 | 35 | 87 | 900 | 5.7 |
| 6SP-51-50 | 51±1.0 | 71±1.5 | 66.8±1.0 | 45 | 87 | 1000 | 6.2 |
| 4SP-64-35 | 64±1.2 | 85±1.5 | 78±1.0 | 35 | 87 | 1100 | 6.7 |
| 4SP-76-35 | 76±1.4 | 107±2.0 | 101±2.0 | 35 | 87 | 1200 | 16.2 |
| 4SP-89-35 | 89±1.4 | 122±2.0 | 114±2.0 | 35 | 87 | 1300 | 18.4 |
| 4SP-102-35 | 102±1.5 | 139±2.0 | 132±2.0 | 35 | 87 | 1400 | 20.3 |
Six layer technical performance index
| Hose code | ID mm | OD mm | Winding layer ID mm | WP MPa | BP MPa | Bend Radius mm | Weight kg/m |
Number*ID*WP MPa | |||||||
| 4SP-51-35 | 51±1.0 | 69±1.5 | 63.8±1.0 | 35 | 87 | 900 | 5.7 |
| 6SP-51-70 | 51±1.0 | 72±1.5 | 66.8±1.0 | 70 | 175 | 1000 | 6.2 |
| 6SP-64-70 | 64±1.2 | 88±1.5 | 81±1.0 | 70 | 175 | 1200 | 7.4 |
| 6SP-76-70 | 76±1.4 | 116±2.0 | 09±2.0 | 70 | 175 | 1300 | 23.7 |
| 6SP-89-70 | 89±1.4 | 129±2.0 | 122±2.0 | 70 | 175 | 1400 | 26.6 |
| 6SP-102-70 | 102±1.5 | 142±2.0 | 135±2.0 | 70 | 175 | 1600 | 29.8 |
