Home > Chemicals > Rubber & Rubber Products > Rubber Tube, Pipe & Hose > China Best Quality Hydraulic Rubber Hose

China Best Quality Hydraulic Rubber Hose

Name: China Best Quality Hydraulic Rubber Hose
Brand: Sufeite, Sufeite
SKU: 121413289

China Best Quality Hydraulic Rubber Hose thumbnail-1

China Best Quality Hydraulic Rubber Hose thumbnail-2

China Best Quality Hydraulic Rubber Hose thumbnail-3

China Best Quality Hydraulic Rubber Hose thumbnail-4

China Best Quality Hydraulic Rubber Hose thumbnail-5

China Best Quality Hydraulic Rubber Hose photo-1

China Best Quality Hydraulic Rubber Hose photo-2

China Best Quality Hydraulic Rubber Hose photo-3

China Best Quality Hydraulic Rubber Hose photo-4

China Best Quality Hydraulic Rubber Hose photo-5

US$ 0.5 - 9.5 MOQ: 50 Meters

Key Specifications

Get Latest Price

Place of Origin:

Hebei, China

Brand Name:

Sufeite, Sufeite

Model Number:

SAE/DIN, R1AT/1SN, R2AT/2SN, 4SH, 4SP

Contact Supplier Request Quote Chat Now

Hengshui Soft Tube Industry Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

TIANJIN

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Hebei, China

Brand Name Sufeite, Sufeite

Model Number SAE/DIN, R1AT/1SN, R2AT/2SN, 4SH, 4SP

SAE 100 R1AT / DIN EN 853 1SN STANDARD

Tube : Oil resistant synthetic rubber Reinforcement : one high tensile steel wire braid Cover : Abrasion and weather resistant synthetic rubber Temperature range : -40 ℃ to +100 ℃

DN	Hose I.D		Wire O.D	Hose O.D	Working Pressure		Burst Pressure		Minimum Bend Radius	Weight	Length
DN	inch	mm	mm	mm	MPa	psi	MPa	psi	mm	kg/m	metres
5	3/16	4.8	9.5	11.8	25.0	3630	100.0	14280	89	0.19	50/100
6	1/4	6.4	11.1	13.4	22.5	3270	90.0	12840	102	0.21	50/100
8	5/16	7.9	12.7	15.0	21.5	3120	85.0	12280	114	0.24	50/100
10	3/8	9.5	15.1	17.4	18.0	2615	72.0	10280	127	0.33	50/100
13	1/2	12.7	18.3	20.6	16.0	2320	64.0	9180	178	0.41	50/100
16	5/8	15.9	21.4	23.7	13.0	1890	52.0	7420	203	0.45	50/100
19	3/4	19.0	25.4	27.7	10.5	1530	42.0	6000	241	0.58	50/100
25	1	25.4	33.3	35.6	8.8	1280	35.0	5020	305	0.88	50
32	1 1/4	31.8	40.5	43.5	6.3	920	25.0	3600	419	1.23	20 to 40
38	1 1/2	38.1	46.8	50.6	5.0	730	20.0	2860	508	1.51	20 to 40
51	2	50.8	60.2	64.0	4.0	580	16.0	2280	635	1.97	20 to 40

Details about steel wire braided high pressure hydraulic rubber hose.

Section of one layer of steel wire braided hydraulic hose

Section of two layers of steel wire braided hydraulic hose

Section of four spiraled steel wire braided hydraulic hose

good degree of adhesion

About us

We are the manufacture specialized in producing all kinds of rubber hoses for more than 20 years, main product is hydraulic hose, air water hose, teflon tube, oil fuel hose, steam hose and brake copper tube.We can export the goods by ourselves. So the price will be competitive than the trading company. Our hoses are exported to America, Europe, South Asia, Middle East, South Africa and so on.
