Fine Wire Braided high&middle pressure synthetic fibre braded rubber resin hose
We develop and manufacture hoses and hose assemblies for :
--Refueling system
--Chemical and pharmaceutical industry
--Industrial hydraulic systems
--Air conditioners in industrial and construction –site vehicles
--Food and beverage industry
--Special and standard industrial applications
--Water and cleaning management
Hose Construction:
Application: ideally suited for medium pressure hydraulic oil lines, return lines, grease lines, water lines and power steering hoses
Rubber Hose Tube:oil resistant synthetic rubber
Rubber Hose Reinforcement: one high tensile synthetic textile braid
Rubber Hose Cover:abrasion,ozone and weather resistant synthetic rubber.
Working Temperature range:-40 °c to 121 °c.
Note: We can produce smooth cover and cloth cover hose.
| I.D | O.D | Working pressure | Burst pressure | Bend radius | Weight | ||
| mm | inch | mm | bar | psi | bar | mm | kg/m |
| 4.8 | 3/16 | 12.5 | 250 | 3630 | 1000 | 89 | 0.19 |
| 6.4 | 1/4 | 14.1 | 225 | 3270 | 900 | 102 | 0.21 |
| 7.9 | 5/16 | 15.7 | 215 | 3120 | 850 | 114 | 0.24 |
| 9.5 | 3/8 | 18.1 | 180 | 2615 | 720 | 127 | 0.33 |
| 12.7 | 1/2 | 21.5 | 160 | 2320 | 640 | 178 | 0.41 |
| 15.9 | 5/8 | 24.7 | 130 | 1890 | 520 | 203 | 0.45 |
| 19.0 | 3/4 | 28.6 | 105 | 1530 | 420 | 241 | 0.58 |
| 25.4 | 1 | 36.6 | 88 | 1280 | 350 | 305 | 0.88 |
| 31.8 | 1-1/4 | 44.8 | 63 | 920 | 250 | 419 | 1.23 |
| 38.1 | 1-1/2 | 52.0 | 50 | 730 | 200 | 508 | 1.51 |
| 50.8 | 2 | 65.9 | 40 | 580 | 160 | 635 | 1.97 |
