CONSMAC Plaster Machine P22

CONSMAC Plaster Machine P22 photo-1
US$ 5,000 - 10,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Automatic Grade:
Automatic
Power(W):
4.0kw, 220V/380V/415V, 50hz/60Hz
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Automatic Grade Automatic
Power(W) 4.0kw, 220V/380V/415V, 50hz/60Hz
Rendering Thickness 6 mm
Rendering Height 15 m
Place of Origin Zhejiang, China
Brand Name CONSMAC, CONSMAC
Model Number P25, P22
Dimension(L*W*H) 130*74*122cm, 130*74*122cm
Weight 205kg, 205kg
Certification CE, CE
Warranty 12 monthS, 12 months





CONSMAC PLASTER MACHINE P22

Three phase, 220V/380V/415V,plastering machine for ready-mixed dry plasters with innovative solutions able to grant higher productivity and reliability. Ideal for mixing and sparying cement, gypsum or insulating ready-mixed plasters.



Genuine added value for a widerange of plastering jobs and special applications



The P22  is mixing and conveying material with a maximum grain size of 3 mm, whether interior or exterior plastering with pre-mix material, gypsum plaster lime cement and cement plaster, paste-like and fluid materials, leveling compound, adhesive, undercoat, paint and other EIFS products



A powerful engine with integral frequency converter and mixing pipe with intelligent design make it possible. The machine only requires a 220V/380V/415V connection to operate on small construction sites and complete refurbishment jobs



Top marks for functional design: You will notice the difference during operation, transport, set-up and cleaning because the low weight and ease of disassembly make the machine extremely simple to handle.





CONSMAC PLASTER MACHINE P22 SPECIFICATION



Applications:
For Spraying, Conveying, Grouting of mixed cement mortar, readymix dry mortar, and  Secondary grouting material.
With variable-speed motor (two speed), vibration screen, Spray gun stop/start control.
With Mixer.



CONSMAC PLASTER MACHINE P22 TECHNICAL DATA





Model P22
Air compressor Including
Pump delivery 22L/min
Hopper volume 45L
Grain size <3mm
Delivery height max 15m
Delivery distance max 40m
Running pressure 30bar
Motor power Electric Motor Three phase
4.0kw, 220V/380V/415V, 50hz/60Hz
For compressor 2.2kw
For water pump 0.37kw
Total weight 205kg
Overall dimensions 130*74*122cm




Standard Assy.
A. mortar pipe of Φ32mm*10m: 1 piece,
B. trachea of Φ8mm*20m: 1 piece,
C. spray gun (nozzle): 1 piece,
D. repair kit: 1 piece.





CONSMAC PLASTER MACHINE P22 Advantage

Equipment features of the plastering machine P22:

  • Versatile and multifunctional
  • Conveying dry and wet mortar with max. grain size of 3 mm
  • 220V/380V/415V drive
  • Compact design
  • Low weight
  • Easy handling (transport)
  • Easy to clean
  • Fully equipped as standard





Payment Terms

1. Standard T/T

2. L/C at sight

3. D/P negotiable







Packing Information

 Wooden Case or as customer' requirement







CONSMAC PLASTER MACHINE P22 PHOTO

CONSMAC plaster machine P22





 CONSMAC plaster machine P22CONSMAC plaster machine P22





CONSMAC plaster machine P22



CONSMAC plaster machine P22
