Specifications
ISO9001-2008,SGS1 Concise structure
2 Good quality
3 Easy maintenance
4 Stable performance
Application of breaker crusher
1. Jaw crusher is suitable for crushing a variety of soft and hard ores and rocks, whose largest compression resistance is under 320MPa. Maximum size of to- be- fed materials must be less than what is required according to the maximum specification of technical parameters.
2.Jaw crusher is mainly used for secondary and fine crushing of mid hardness ores and rocks in metallurgical industry, mining, chemistry, cement making industry, construction, refractory, pottery, porcelain industry, etc. All models of stone jaw crushers are available according to your different fineness requirements.
Advantages of breaker crusher
1. Big crushing ratio;
2. Uniform products size;
3. Easy maintenance;
4. Wide range discharge opening, can meet the requirements of different users;
5. Lubrication system safe & reliable, convenient replacement for parts, easy maintenance;
Benefits of breaker crusher
1.The bearings adopt complete steel structure. The whole cast steel housing can fully coordinate with the rack. Meanwhile, it greatly enhances the radial intensity of the bearings.
2.The applications of finite element analysis technology can greatly strengthen the efficiency of crushing process.
3. It is more convenient to adjust the discharging mouth. The adjusting device is equipped with wedge block, while our devices are simpler and safer than the old-fashioned ones.
Working principle of breaker crusher
Firstly the machine’s leather belt and wheel are driven by the electric motor, then the movable jaw plate begins to move up and down by the eccentric shaft, when the movable jaw plate moves from top to bottom, the angle between fixed jaw plate and movable jaw plate becomes smaller, the material is crushed into pieces to reach the crushing target. When the movable jaw plate moves from bottom to top, the angle between fixed jaw plate and movable jaw plate becomes bigger, the movable jaw plate deviates from the fixed jaw plate under the function of drag rod and spring, at this moment, the crushed material is discharged from the bottom outlet of the crushing cavity.
Technical parameters of breaker crusher
| Model | Feeding Size (mm) |
Max Feeding Size (mm) |
Discharging Size (mm) |
Capacity (m3/h) |
Motor Power (kw) |
Weight (t) |
| PE250*400 | 250*400 | 210 | 20-60 | 3-13 | 15 | 2.8 |
| PE400*600 | 400*600 | 340 | 40-100 | 10-35 | 30 | 6.5 |
| PE500*750 | 500*750 | 425 | 50-100 | 25-60 | 55 | 10.6 |
| PE600*900 | 600*900 | 500 | 65-180 | 30-85 | 55-75 | 15.5 |
| PE750*1060 | 750*1060 | 630 | 80-180 | 72-150 | 90-110 | 28 |
| PE800*1060 | 800*1060 | 680 | 100-200 | 85-143 | 90-110 | 30 |
| PE870*1060 | 870*1060 | 750 | 170-270 | 145-235 | 90-110 | 30.5 |
| PE900*1060 | 900*1060 | 780 | 200-290 | 170-250 | 90-110 | 31 |
| PE900*1200 | 900*1200 | 780 | 95-225 | 100-240 | 110-132 | 49 |
| PE1000*1200 | 1000*1200 | 850 | 195-280 | 190-275 | 110-132 | 51 |
| PE1200*1500 | 1200*1500 | 1020 | 150-300 | 250-500 | 160 | 100.9 |
| PEX150*750 | 150*750 | 120 | 18-48 | 5-16 | 15 | 3.5 |
| PEX250*750 | 250*750 | 210 | 25-60 | 8-22 | 22 | 4.9 |
| PEX250*1000 | 250*1000 | 210 | 25-60 | 10-32 | 30-37 | 6.5 |
| PEX250*1200 | 250*1200 | 210 | 25-60 | 13-38 | 37 | 7.7 |
| PEX300*1300 | 300*1300 | 250 | 20-90 | 10-65 | 75 | 11 |
Training & service of Zhengzhou Taida
Training is FREE to every customer. Whenever you need us, for installation, maintenance, or proper use of our company machines, we will be right there for you. In addition, we provide 2-years warranty to make sure your machine runs consistently. We always keep certain inventory level of spare parts, which means the replacements can be shipped to you right away.
Taida Energy-saving drying company
We are manufacturer in drying machine more then 25 years in Zhengzhou, which serves as the largest base of Chinese industrial technology, and the busiest container port in the world. The competition in this city is severe, only companies with ending technology, stable workforce, and effective cost management could survive. With 25 years of efforts and innovation, our company is now a leading brand in China.
Affordable, high-quality machines. Our highly competitive price relies upon our ability to minimize our costs, of which our competitors don’t.
1. We are factory(NOT Dealer)
2. We own our factory & Land (NOT Rent)
3. Staff reside in factory(Stable Workforce)
Producing high-quality and reliable machines is always our first priority, because we know that our success depends entirely on the satisfaction of our customers. We never give-up quality to save cost, instead we manufacture our machines to supply you the best need.
If you have any other questions about our products, you may contact Frank
through skype: TDfrank006
Taida Company certificates
