Specifications
Printhead: Xaar382 Proton/35/60pl *4/8Max.Resolution: 240*1080dpi
Max.Speed: 68sqm/h (8*3pass@360*540dpi)
Super Competitive!
LIYU Evolution PE Series Inkjet Printer
Data Specifications:
Model |
PE Series Solvent Inkjet Printer |
|||
Printhead model |
Xaar 382/35pls/60pls |
|||
Printing resolution |
360 dpi/ 720 dpi 240 dpi/ 720 dpi Max. 1440 dpi |
|||
Media thickness |
Max. 2mm |
|||
Media operation |
Roll to roll and soft media |
|||
Max media width |
3,300mm |
|||
Max printing width |
3.200mm |
|||
Model |
PE3204 |
PE3206 |
PE3208 |
|
Number of printheads |
4 |
6 |
8 |
|
Printing speed |
Draft mode |
50 sqm/h |
50 sqm/h |
81 sqm/h |
|
Production mode |
38 sqm/h |
38 sqm/h |
61 sqm/h |
|
High quality mode |
25 sqm/h |
25 sqm/h |
40 sqm/h |
Ink |
Color |
4 |
6 |
4 |
Type |
Xaar approved solvent ink (two years outdoor duration) |
|||
Ink drying system |
Preheating, postheating, drying fan and additional drying tools (optional) |
|||
Ink supply system |
Automatic ink supply system |
|||
Media |
Type |
Soft media, including PE, PP, ABS, PS, PU, mesh fabrics and PVC |
||
Roll-to-roll feeding system |
Automatic feeding system |
|||
Printhead maintenance system |
Automatic flash jet |
|||
Printing flow |
Operate directly through RIP software |
|||
Interface |
USB 2.0 |
|||
RIP software |
ColorPRINT/UltraPrint (optional)/Photoprint (optional) |
|||
Operating System |
Windows XP |
|||
Recommended PC configuration |
CPU |
Core™ 2 CPU @ 2.0GHZ or higher |
||
Memory |
2 GB or higher |
|||
Hard drive |
Min. 160 GB |
|||
Power consumption |
220V 25A |
|||
Working environment |
Humidity |
45-75% RH |
||
Temperature |
Ideal temperature 20-30°C (68-86°F) |
|||
Gross weight |
kg |
450 KG |
||
Note: Specifications are subject to change without prior notice, all rights reserved. | ||||
Highlight Features:
1. Branded high-precision linear guide, Panasonic servo motor enables higher carriage speed and lower noise.
2. The printing platform enjoys one big Globoidal heating system, faster integration of ink and media to enhance the durability of the printing photos;
3. Encoder stepper system, step moves more accurate and stable.
4. Printhead ink entrance mouth enjoys a 10um imported original filter, which prevents the heads from pollution.
5. Independent research and development of dual optical fiber systems ensures print data transmission more efficient and stable.
