Specifications
The Inkjet Printer is amazing fast with high quality, efficiency improved 55% more than a similar printer which with KM512/42pl!LIYU Maxima PZ-KX Inkjet Printer:
Data Specifications: | ||
MODEL |
PZ3204/PZ3206-KX |
PZ 3208-KX |
Print Tech |
Piezo continuous drop-on demand(DOD) |
|
Print Head |
4/6×KM512LNX(35pl) |
8×KM512LNX(35pl) |
Print Resolution |
Max. 360*1440dpi |
|
Image Size |
3.20m / 126in. |
|
Media Size |
3.29m / 130in. |
|
Media Type |
/ Banner, Vinyl, One-way Vision, Coating Film, etc… |
|
Media Transmission |
Roll to Roll |
|
Printing Speed |
Draft Mode: 60m2/h Production Mode: 39m2/h Quality mode: 30m2/h |
Draft Mode: 115m2/h Production Mode: 74m2/h Quality mode: 56m2/h |
Ink Type |
CMYK or CMYKLcLm |
|
Interface |
USB2.0 |
|
Auto.take-up and feeding system |
Equipped |
|
Heating System |
Three Sections of pre-heat, heat post- heat |
|
Ventilation System |
Optional |
|
Packing Size(w×d×h) |
4.57m*1.00m*1.60m (179.9* 39.4 * 63.0in.) |
|
G.Weight |
650Kg |
|
Power Requirement |
110V / 220±10%, >10A, 50 / 60Hz |
|
Environment |
Temperature:20°C~30°C, Humidity:40%~70%RH |
|
Outdoors Durability |
2 years |
|
| ||
Specifications are subject to change without prior notice, all rights reserved. | ||
Highlight Features:
1. The PZ-KX Series is ideal for high-volume production printing in amazing quality(efficiency improved around 55% more than a similar printer which equipped with KM512/42pl) with KM512/35pl print-heads,Max. Resolution up to 360*1440dpi.
2. Designed for high-volume printing and rush jobs, the PZ-KX with 8 heads of dual CMYK produces billboards, banners, backlit, fleet and vehicle graphics, and point of purchase displays at a maximum print speed of up to 190 m2/hr at 1pass, carriage speed reaches up to 1.3m/s.
3. Famous imported high-precision & Silent linear guider, Panasonic servo motor enables higher carriage speed and lower noise.
4. 2 grade gear drive system ensures more accurate step and media feeding.
5. Broadbanding printing and heating platform, plus the powerful cooling&hot fans system quickly dries ink and medias for high-speed applications.
6. Adopted the Negative Pressure System enables the very high speed printing stable and smoothly.
7 Independent research and developed LIYU New Vision of three-optical -fiber high speed data transmission system, guarantied machine quality, after-sales Worry-free.
8. The latest new Optional functions (attached with Photo descriptions):
Automatic Media-check system, Automatic Printhead Capping & Cleaning system.
Carriage Cooling System, Printhead Plate heating system, Infrared heating system,fume exhausting system.
