Home > Packaging & Printing > Printing Machinery > Pad Printer > LIYU Victor KJ-II Series UV Flatbed Printer

LIYU Victor KJ-II Series UV Flatbed Printer

Name: LIYU Victor KJ-II Series UV Flatbed Printer
Brand: LIYU
SKU: 121387633

LIYU Victor KJ-II Series UV Flatbed Printer thumbnail-1

LIYU Victor KJ-II Series UV Flatbed Printer photo-1

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Condition:

New

Plate Type:

Flatbed Printer

Place of Origin:

Anhui, China

Contact Supplier Request Quote Chat Now

Anhui Liyu Computer Equipment Manu. Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Plate Type Flatbed Printer

Place of Origin Anhui, China

Brand Name LIYU

Model Number KJ3020-II / KJ2518-II / KJ2512-II

Usage Other, All kinds of Flexible and Rigid media

Automatic Grade Automatic

Gross Power 110V/220V±10% 60/50HZ, 380V±10% 50HZ

Dimensions(L*W*H) 4960*2885*1295mm;4416*2885*1295mm;4416*2065*1295mm

Specifications

LIYU Victor KJ-II series UV Flatbed Printer is Luxury updated, profitable, far-ranging applications with good market prospects.

LIYU Victor KJ series UV Flatbed Printer:

Data Specifications:
Model		KJ3020-II / KJ2518-II / KJ2512-II
Head Options		4 Colors(+White+Varnish)			6 Colors(+White+Varnish)
		CMYK(+W+V)/CMYK*2			CMKYLcLm(+W + V)
Printhead		KM1024MH
Head Control		Temperature and head voltage control by Software
Head Quan.		4/6/8pcs
Media Size		3000mm×2000mm /2500mm×2000mm /2500mm×1230mm
Resolution		360×720, 360×1080, 360×1440, 720×720, 720×1080, 720×1440(dpi)
Speed	Head Quan.	8		4			6
	Draft Mode	79.2 m²/h		39.6 m²/h			39.6 m²/h
	Prod. Mode	54.4 m²/h		27.2 m²/h			27.2 m²/h
	Quality Mode	43.6 m²/h		21.8 m²/h			21.8 m²/h
Drying System		UV Lamp (Shutter Optional)
Anti-static System		Optional
Max. Media Thickness		0~100mm
Table Pressure		100kg/m2
Interface		USB2.0
Power		110V/220V±10% 60/50HZ, 380V±10% 50HZ
Environment		Temperature: 15 0C ~ 30 0C Humidity: 40% ~ 80%
Machine Size		4960×2885×1295mm	4416×2885×1295mm			4416×2065×1295mm
Net Weight		1450kg	1250kg			1100kg

Specifications are subject to change without prior notice, all rights reserved.

1.Printhead Characteristics: Adopt the advanced Japanese Konica UV specialized head, 1024 nozzels double staggered, built-in temperature control system, real printing resolution up to 1440dpi,printing speed double compared to the KM512MH.

2.Type of Media: glass, ceramic, aluminum, wood, doors, cardboard, Chevron board, ceiling, MDF, metal lacquer panels, toilet cover, acrylic, plexiglass, etc.

3.Mechanic Superiority: dual lead screw & dual linear guide broadside scanning mechanical structure, industry-leading machinery precision; Table loading capacity of 100kg/sqm, crossbeam up and down automatically, maximum media thickness up to 100mm; Sub-vacuum absorption table enables the printing on different sizes of media; Auto. detection of media, Auto. detection of Origin, pneumatic medium jack-up system plus rolling bearings enables even a single person can load the large-format media easily.

4.Electronic control Superiority: Independent developed entire control system, classic combination of USB and Three-Optical fiber far speed data transmission system, LIYU patent software control system, have experienced numerous customers trials.

5.Pressure & Ink supply control: Closed-loop automatic control, reliable printing quality; pneumatic control components imported from Japan, guaranteed quality; LIYU patent Valve cleaning system, easy to maintain.

6. Main tank ink level display function, brand new and user-friendly design of control panel, makes the human-computer communication more intuitive, convenient and faster.

7. More Color options: The Machine can be configured as KCMY / KCMY + W + V / KCMY LC LM / KCMY LC LM + W + V; Moreover, the machine could achieve the bed and cover coating or spot-color printing.
