Home > Products > Spare Parts > Mini Size PVC/PE Blown PE Film Blowing Machine
Mini Size PVC/PE Blown PE Film Blowing Machine
- Ningbo Shanghai Port
- T/T
You May Like
-
Film Full-auto Mold Film SJ-A HDfilm/LLDfilm Mini Type Film Film Aoxiang Printing Connect- Line Set
-
Film ns Full Automatic Factory Supplier Mini Size PVC/film Blown Film Film Machine Aoxiang Printing Connect- Line Set
-
MiniBest Polythene Protective Film SJ-A HD/LLD Mini Type Best Polythene Protective Film Ruian(CPHL) Printing Connect- Line Set
-
Ldpe Film Stretch SJ-A HD/LLD Mini Type Ldpe Film Stretch Machine Printing Connect- Line Set
-
Film Bags Unit Full Automatic Factory Supplier Mini Size PVC/film Bag Blown Film Bag Machine Printing Connect- Line Set
-
Mini Size PVC/ Blown Machine 5 Gallon Double- Film Set Laminat 200 Litre Plastic Drum Plastic Film Blow and Print
Product Details
| Condition | New | Application | Film | |
| Plastic Processed | PE | Blow Moulding Type | Extrusion Blow Moulding | |
| Automatic | Yes | Place of Origin | Zhejiang, China | |
| Brand Name | AX | Model Number | SD-45 | |
| Voltage | 380V | Power(W) | 30kw | |
| Dimension(L*W*H) | 4*2*3.8m | Weight | 1200kg | |
| Certification | CE | Warranty | 1YEAR | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
Auto LoaderFilm Surface Treater
Die Rotary Device
Air Compressor
usage:
It is used for blowing various plastic film of low density polyethylene(LDPE), high density polyene(HDPE) and linear low density polyethylene(LLDPE) etc., which are widely used for packing liquid, industrial products, garments and textile and printing lamination.etc.. The cylinder and the screw stems of the extruder are made of high-quality alloy steel with optimum hardness and strong corrosion resistance after nitrogen treatment and precision finishing. The auxiliary machine has a platform working table formaking operation easy and is equipped with dubble stabilizing ring. Double-rolling and double-cutting coiling unit adopts torque motor to keep proper tension and make even and roll-changing easy.
Main Specification
| Packaging Detail: | in bulks or wooden box packing the parts together. |
| Delivery Detail: | within 15 days delivery it |
MODEL | DR-SJ45-400 |
Suitable raw material | HDPE LDPE LLDPE |
Screw diameter | 45mm |
L/D ratio | 28:1 |
Screw speed | 15-100r/min |
Main motor power | 7.5kw |
Output capacity | 25kg/h |
Die specification | 50mm |
Film thickness | 0.008-0.08mm |
Film width | 80-400mm |
Total power | 18kw |
Weight | 1800kg |
Dimension | 2.4×2.1×2.8m |
Picture Detail:
Welcome to visit our factry:
Contact Us
- Ruian Aoxiang Packing Machine Co., Ltd.
- Contact nameLidou Su Chat Now
- Phone86-577-25665508
- AddressFuqiang South Road Xincheng Industrial Area, Ruian City, Wenzhou, Zhejiang
