Home > Products > New Products > 1-CH CCTV UTP Active Video Balun Receiver
1-CH CCTV UTP Active Video Balun Receiver
- 3000 Piece / Pieces per Month
- Shenzhen(Optional)
- Credit Card
You May Like
-
4-Channel CCTV UTP RJ45 to BNC Video Balun
-
1 Channel Passive Video UTP Transmitter and Receiver
-
4-CH Passive UTP video Balun Transmitter and receiver
-
Anti-interference Function 16 channels video active UTP transmitter and receiver
-
1 Channel active UTP Video Balun for CCTV camera
-
multi active video balun / UTP transceiver
Product Details
| Place of Origin | Hubei, China | Brand Name | CY | |
| Model Number | CY-101PT |
Product Description
Specifications
1 Distance up to 1200M.2 Anti-jamming, surge protection..
3 Got CE,FCC,ROHS Certification.
4 AC/DC 12V-24V.
Technical Parameters
Type | 1V (Passive) | 4V 1D V1 | 8V (Passive) | 8/16/32V (Passive) 19”1URack | 1V (passive) | 1V 1D 1A | 4V (Active) | 8/16/24V (Active) 19”1U rack | |||
Video | Frequency response range: DC-8MHz; common-mode rejection/Differential Mode Rejection Ratio: 15KHz-8MHz 60dB(typical value) | ||||||||||
Wire Type | Class 3 or above wire(0.48-1.31mm); DC loop resistance of each wire core pair 18Ω/100m, Differential capacitance 62pF/m | ||||||||||
Impedance Feature | Twisted wire, binding post or RJ45: 100Ω; Video BNC or coaxial cable: 75Ω | ||||||||||
Power | / | / | / | / | AC-DC 12-24V80mA | 12V 300mA | AC 100-240V 50/60Hz | ||||
Transient Protection | / | / | / | / | 6KV 10/700us IEC61000-4-5 (ground benigh) | ||||||
Volume (mm) | 47X15X16 | 81X82X29 | 120X78X32 | 432X97X44 | 81X82X29 | 81X82X29 | 120X97X32 | 432X97X44 | |||
Weight(g) | C-20; L-16 | 100 | 210 | 1010/1110/1310 | 88 | 120 | 220 | 1200/1320/1500 | |||
Working Environment | Temperature Range(-20~60°C) | ||||||||||
Relative Humidity Range(0~95% non-condensing) | |||||||||||
