HD CVI Fiber Optic Video Transmitter and Receiver
- 10000 Pair / Pairs per Month
- Shenzhen
- T/T L/C D/P D/A Credit Card PayPal
- ZTE 5928E, RS-5928E, RS-59EC-PWR-AC10, RS-59EC-PWR-DC10, 24 GE RJ45 + 1 expansion card ZTE ZXR10 5928E 5952E 5916E RS-5916E RS-
- ZTE 2952E, RS-2952E-AC, RS-2952E-DC, 48 FE RJ45 4 GE SFP ZTE ZXR10 2952E 2928E 2918E 2910E
- ZTE 3950-28TM, RS-3950-28TM-AC, 24 FE RJ45 + 2 GE SFP + 1 expansion card slot ZTE ZXR10 3950
- ZTE 2950-18TC, RS-2950-18TC-AC, 16 FE RJ45 + 2 GE Combo ZTE ZXR10 2950
- ZTE S2XF48A, 48-port 10GE SFP+ optical interface ZTE ZXR10 8902E 8905E 8908E 8912E RS-8902E RS-8905E RS-8908E RS-8912E
- ZTE 5250-28PM-H, RS-5250-28PM-H, 20 GE RJ45 (POE/POE+) + 4 GE Combo ports + 1 expansion card ZTE ZXR10 5250
Product Details
Place of Origin: | Henan, China | Brand Name: | chuangyuan | Model Number: | CY-9804C/7 |
Product Description
HD CVI Fiber Optic Video Transmitter and Receiver
Description
HD CVI Fiber Optic Video Transmitter and Receiver can simultaneously transmit 1-16 channels HDCVI over one multi-mode or single-mode optical fiber. Electronic and optical adjustments are never required. LED indicators are provided for instantly monitoring system status. Devices are available for either standalone or rack-mount installation ,which is suitable for different working environment . Compatible with 1280H/25f, 1280H/30f, 1280H/50f, 1280H/60f. Lossless non-compression real time transmission.
Specifications
Optical
Wavelength | 1310nm&1550nm |
Output Power | -8~3dBm |
Optic fiber | 50/125u multi mode,62.5/125u multi mode,9/125u single mode |
Rx sensitivity | -25dBm |
Optical connector | FC,ST,SC (optional) |
Distance | 0~550M (MM) / 0~20KM (SM) |
Video
Number of Channels | 1~16 |
Input/output impedance | BNC 75Ω (unbalance) |
Standard video input/output voltage | 1.0Vp-p |
Video Bandwidth | 45MHz |
Sampling Bandwidth | 10bit |
Sampling Frequency | 108MHz |
Rise and Fall time | <0.8ns |
Optical Signal Intrinsic Jitter | <0.2 UI |
Differential Gain | < ±1.5% |
Differential Phase | < ±1° |
Connector | BNC |
Power | DC5V 2A |
Power Consumption | ≤6W |
Temperature | -40ºC ~75ºC |
Humidity | 10%~90% RH |
Unit Weight | 1.45KG(pair) |
Dimension | 183mm×154mm×30mm |
Installation | Wall mount |
MTBF | ≥ 100000Hours |
System connection diagram
Company Introduction
Established as a high-tech enterprise in 2002, Henan HMCY Electronic & Technology Co., Ltd. is specialized in professional Research & Design, manufacturing, and sales of video transmission equipment in security and surveillance field. With first-class production management and strict quality control system, we have been well-known for our product quality, reasonable price and satisfactory services.
Our main products include fiber optic video converter, coaxial video multiplexer, power video multiplexer, Ethernet media converter, IP to coaxial converter, HD IP Camera, surge protector, video anti-inteference device etc.. All had been approved with CE, FCC, and RoHS certificates.
