China Wholesale Custom large diameter quartz glass tube
Descrption of large diameter quartz glass tube
Introduction of large diameter quartz glass tube:
Round quartz piece produced by flame melting method can be processed into transparent quartz wafer, square piece and flange, and others which will be used for view window, semiconductor quartz fittings, etc.
Also the special size quartz block or quartz plate can be obtained by one more thermal reforming, or quartz tube and quartz rod can be drawn. It can be used as material of semiconductor fittings and auxiliary material of optical fibre. Content of OH is commonly controlled at 120-260ppm.
| JGS-1 | JGS-2 | JGS-3 |
|
| The average transmittance spectra characteristics | 180-2500nm | 200-2500nm | 260-3500nm |
| 90% | 85% | 85% | |
| bubble type | 0 | 2 | 2 |
| birefringence | 1-2 | 1-2 | 1-2 |
| particle structure | 1 | 2 | 2 |
| stripe | 1-2 | 1-2 | 2 |
| homogeneity | 1-2 | 2 | 2 |
| fluorescence | 1 | 2 | 2 |
| Radiation-proof property | Don't change color | Slight discoloration | discoloration |
The physical properties of quartz glass:
sheet 1:
| mechanical property | Standard values |
| standard value | 2.2g/cm3 |
| The compressive strength | 1100Mpa |
| Bending strength | 67Mpa |
| Tensile strength | 48Mpa |
| Poisson's ratioμ | 0.14~0.17 |
| Young's modulusE | 72000Mpa |
| Modulus of rigidity | 31000Mpa |
| Mohs hardness | 5.5~6.5 |
| Thermal performance | Standard values |
| The deformation points | 1280℃ |
| Softening point | 1780℃ |
| Annealing temperature | 1250℃ |
| Specific heat (20 ~ 350 ℃) | 670J/kg.℃ |
| Thermal conductivity (20 ℃) | 1.4W/m.℃ |
| The refractive index | 1.4585 |
| Thermal expansion coefficient | 5.5×10-7cm/cm. ℃ |
| Hot working temperature | 1750~2050℃ |
| Short-term use temperature | 1300℃ |
| Long-term use of temperature | 1100℃ |
China Nantong Yinxing Optical Co.,Ltd., founded in the early 1980s, situated in Jiangsu Province of China, is a
large optical glass manufacturer. It major supplies include colored and uncolored optical glass,optical coating filters,
light and color filters, color filtering lens, insulating glass, quartz glass, infrared penetrating glass, near-infrared
penetrating glass, UV glass, black UV penetrating glass (wavelengths: 254nm, 310nm, 365nm), ND glass, orange, green
and yellow glass, band-pass filter, and filters for currency count machine. Their applications include mainly photographing
apparatus, meter and instrument, optical devices, medical treatment apparatus, teaching apparatus, projectors, UV analyzers,
financial equipment, airport lamps and military equipment, technological research institutes and public security
departments. The products have been exported to Europe, the US, Southeast Asia, Japan, South Korea, Hong Kong,
Macao and Taiwan and been highly recognized by users..
For a long period, we have been in pursuit of sound cooperation relationships with our clients, anchored by corporate
spirit of integrity, good faith and diligence, quality products and competitive prices. The company embraces the team
spirit of preciseness, efficiency and collaboration, makes innovations and progress continuously, and endeavors to
develop into the largest, strongest and best optical glass manufacturer in China.
Looking into the future, we are confident. The developing China Nantong Yinxing Optical Co.,Ltd. is aiming to reach
a new peak, to make more outstanding contributions to the development of the optical glass sector with improved quality
products and services, and to create a brighter future for the enterprise. 35years professional experience in optical filter ,
Uv filter, Borosilicate Glass manufacture,we supply filters from UV to near-infrared.quartz glass! Superior quality, low price,
perfect service. Large supply optical filter , Uv filter, Borosilicate Glass.
High hydrolytic resistance
Excellent resistance to acids
High resistance to alkalis
Low alkali diffusion
Very good temperature stability
Optical filters are flexible packaging in carton. There are several different size of the carton, 20*25*15cm;
45*40*25cm; 60*50*35cm. We can make sure the safety of the optical filters during shipping
