1.1KW Solar Water Pumping System
US$ 2,200 - 2,500
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Zhejiang, China
Brand Name:
Green Answer
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai/Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
7.5KW Solar Pump for Deep WellUS$ 11,000 - 15,000MOQ: 1 Set -
7.5KW Solar Pump InverterUS$ 8,000 - 11,000MOQ: 1 Set
-
2.2KW Solar Water Pumping SystemUS$ 4,400 - 5,000MOQ: 1 Set
-
Solar Water Pump Price---farm Irrigation and Human DrinkingUS$ 10,000 - 90,000MOQ: 1 Set
-
Solar Water Pump for AgricultureUS$ 11,000 - 15,000MOQ: 1 Set
Condition
New
Place of Origin
Zhejiang, China
Brand Name
Green Answer
Model Number
SP1.1K
Material
Other, Steel
Feature
GSM Remote Control
After-sales Service Provided
Engineers available to service machinery overseas
- Features:
AC Wate Pump
-
Power: 1.1kW
- Voltage: 3-phase 380V AC, 50Hz
- Type: multi-stage centrifugal submersible pump
- Series: water cooling and reinforced motor suitable for solar power
- Max. flow: 36m3/hour
- Max. head: 134m
- Outlet: 1.25/1.5/2/2.5/3 inches
- NEMA standard: 96mm
- Diving depth: ≤50m
- Materials:
- Water outlet: 304 stainless steel
- Impeller: 304 stainless steel
- Pump body: 304 stainless steel
- Motor casing: 304 stainless steel
- Motor shaft: 304 stainless steel
- Screw: 304 stainless steel
- Upper guide bearing, thrust bearing base: cast iron, can be updated to be stainless steel with extra cost if needed
- Water quality: sand content (weight ratio) in water should not exceed 0.01%, chlorine content should not be over 400mg/L
- Max average daily water supply: 200m³ at 5.5KWh/m²/day
- Warranty: 18 months, extend to 2-year warranty optional with extra cost
- Advantages: up to 15yrs lifespan, working is reliable and stable
-
Controller and inverter:
- Power: 1.5kW
- Input voltage range: 330-710V
- Output voltage: AC, 3-phase 380V
- MPPT range: 450-600V
- Max MPPT efficiency: ≥97%, soft start/stop
- Warranty: 2-year, extended to 3-year warranty optional with extra cost
- Protection:
- Over-current, over-voltage, over-speed, over-temperature
- Reverse polarity
- Dry water/phase failure protection
- Advantages: high MPPT efficiency function, GMS remote control, auxiliary diesel power/3 phase AC electricity hybrid power transfer-switch controller, water flow control regulator, soft start/stop
-
Solar panel reference:
- Power: mono/poly, totally about 1500W
- Positive tolerance: +0/5W
- Products warranty: 10 years
- Performance warranty: 90%/10 years, 80%/25 years
-
Mounting system:
- Type: fixed mode/pillar manual tracking/slanting uniaxial tracking
- Foundation: concrete pouring
- Installation type: 6 pieces/array and vertical
- Warranty: 5 years
- Material: hot-dip galvanized
- Combiner box: N/A
- Accessories: PV cables, water pump cables, water level detective sensor, cable sleeves, pipeline, flange, riser pipe
- The quantity of accessory materials are based on actual design
-
Applications:
- Ecological irrigation
- Solar drought control, living water supply
- Agriculture irrigation
- Solar desert control
- Solar seawater desalination system
- Solar city water landscape
- Pasture irrigation
