ZF-1500mm Automatic Stainless Steel Barrel Longitudinal Seam Welding Machine
Feature longitudinal seam welding machine
1. Welding torch pneumatic moving up and down, the work piece is fixed, seam is flat.
2. Work pieces positioning and centering by pneumatic, and pressing by the pneumatic keys, welding position can not offset.
3. Welding torch can be up and down, left and right, forward and backward and angle adjusted, in order to meet the welding requirements.
4. The control of the whole machine is PLC, AC variable frequency speed regulation, ensures the equipment reliability.
5. Added copper backing strap, ensures reverse side forming.
6. Welding form can be preset, storing and transferring. Through the man-machine interface can easily change the parameter and state transition.
Models longitudinal seam welding machine
Model |
Welding length(mm) |
Min Diameter (mm) |
Max Diameter (mm) |
ZF-500 |
500 |
Φ 75 |
Φ 750 |
ZF-1000 |
1000 |
Φ 100 |
Φ 750 |
ZF-1500 |
1500 |
Φ 120 |
Φ 750 |
ZF-2000 |
2000 |
Φ 160 |
Φ 750 |
ZF-2500 |
2500 |
Φ 200 |
Φ 750 |
ZF-3000 |
3000 |
Φ 270 |
Φ 750 |
Picture longitudinal seam welding machine
Welding Effect longitudinal seam welding machine
Video Link longitudinal seam welding machine
/video.php?v=1524132804493854&set=vb.100006914478186&type=3&theater
Plywood case or plastic film cover
ISO9001:2008 & CE certification
After-sale Service
♥ Warranty one year
♥ Engineers available to serve machine overseas
♥ Strict factory inspection
♥ Complete equipment manual
♥ Online instruction
♥ Provide all components, spare parts and consumptive material
