5E/5L/5VA/6VA manual turret milling machine
- 800 Set / Sets per Month
- SHANGHAI for turret milling machine
- T/T
- YORNEW Desktop CNC Lathe Machine, education cnc, vocation cnc, hobby cnc, diy cnc
- Industrial 4.0 intelligent manufacturing production line, FMS, CIM, training system
- Industrial 4.0 intelligent manufacturing production line, FMS, CIM, training system
- Industrial 4.0 intelligent manufacturing production line, FMS, CIM, training system
- Industrial 4.0 intelligent manufacturing production line, FMS, CIM, training system
- Industrial CNC Milling Machine, production, Machine Center for steel, stainless
Product Details
Condition: | New | Place of Origin: | China | Brand Name: | HHT, HHT |
Model Number: | 5E/5L/5VA/6VA | Type: | Vertical | CNC or Not: | Normal |
Voltage: | 220v/380v | Power(W): | 3HP | Dimension(L*W*H): | 1500*1700*2150mm |
Weight: | 1400kg | Certification: | CE ISO | Warranty: | 1 Year |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Turret milling machine
Turret Milling Machine:
MODE | 5E/5s | 5L/5VA | 6VA |
spindle motor | 5HP | 5HP | 5HP |
spindle taper | NT40 | NT40 | NT40 |
spindle diameter | 105 | 105 | 105 |
Spindle travel | 127 | 127 | 127 |
spindle speed | 80-5440RPM(16Steps) | 80-5440RPM (16Steps) (70-3600RPM) | 80-5440RPM(16Steps) (70-3600RPM) |
Spindle feed of each turn | 0.04 0.08 0.15 | 0.04 0.08 0.15 | 0.04 0.08 0.15 |
Rotary angle of milling head | Left90°Right-90° | Left90°Right-90° | Left90°Right-90° |
T-slots size: | 16*3*65 | 16*3*65 | 16*3*65 |
Max. Load capacity | 400kgs | 500kgs | 500kgs |
working surface size | 1370*280/1370x350 | 1370*280(305) | 1370*330 |
Longitudinal travel | 900/900(800) | 900/800 | 800 |
Transverse travel | 420 | 420 | 390 |
vertical travel | 420/432 | 432/450 | 450 |
Max. Distance between spindle nose and working table | 495/595 | 595/650 | 560 |
Machine Size | 1600*2000*2370 | 2200*1700*2450 | 2200*1700*2450 |
Machine net weight | 1650kgs/1800kgs | 1800kgs/1950kgs | 2100kgs |
a. Free installation and debugging
b. Free operator training
c. Free maintenance within 1 year
d. Long warranty and technology support
a. 30% Deposit by TT before production and 70% payment by TT before shipment;
b. 30% deposit by TT before production and 70% L/C at sight before shipment;
c. 100% L/C at sight.
Wooden case & ocean shipping
Wooden box, or as per customers' requirements.
Before shipment, machines would be painted with rust-proof oil and packed with water-proof material very carefully.
Wooden cases are made of fumigated material and special ordered according to the sizes of different machines. Suitable for transportation and land.
Q1: how to buy the machines from your company?
A1: 1) please send your inquiry from the bottom of the page, or please call us directly. 2) We will discuss more details after getting in touch with each other.
3) Then we send you INVOICE with our bank account and you pay the money;
4) We start production as soon as we get the money;
5) We deliver the machine by sea to the port in your country.
Q2: what is your payment term?
A2: we prefer 30% TT as deposit and 70% TT before sending machine.
Q3: what is your warranty for the machine?
A3: The warranty for the machine is 12 month. Warranty claim for parts that are replaced free of charge in the warranty term owning to failure or damage will be honored. However, artificial damage or damage due to force majeure is not covered under warranty.
Q4: Can we visit your factory?
A4: of course! You are the most welcome to visit our factory and check the machines in person. Please let us know your plan before you come, and we will pick you up in the airport or at station.
Q5: Do we need to install the machines?
A5: For small machines like VMC and CNC Lathe, there is no need to install. We will send the machines as whole part. For large machines, like Gantry Milling machines and Boring Milling machines, you need to install the machines, or we will send our engineers to your place for installation, if it is necessary.
Looking for agents worldwide
With years of development, we have entered into international market and gain good reputation for our machines.
In order to expand our business and bring benefits to our customers as well, our company now is looking for agents worldwide. We have got the agent in Venezuela.
Our company will offer much support for our agents, like discounts for purchasing machines, financial support for taking part in exhibitions, technical support and so on.
And if you have any requirements, please let us know. We will try our best to meet your requirements.
We are looking forward to establish long-term business relationship with you!
