TNC-20H/26H Double Spindle Milling Composite Walk Core Type CNC Lathe

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Type:

Horizontal

CNC or Not:

CNC

Huaian Haoyang Machine Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHANGHAI

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Horizontal

CNC or Not CNC

Automatic Grade Automatic

Place of Origin Yunnan, China

Brand Name HHT

Model Number TNC-20H-26H

Power(W) 3kw/5.5kw

Dimension(L*W*H) 2000*1320*1700mm/2280*1350*17

Weight 2820kg/2950kg

Certification CE ISO

After-sales Service Provided Engineers available to service machinery overseas

Taiwan SYN system auto machine Double spindle milling composite walk core type CNC lathe machine China manufacture TNC-20H/26H

High precision built-in spindle, The sub-spindle adopts mechanical motor drive;
The design of high strength integration improves for difficult to cut materials gravity processing capacity;
You can install a variety of special tools, the tool arrangement model to reduce the tool change time, improve processing efficiency;
High speed high precision and high rigidity cutting composite machine center .
Compact and aesthetic design improves the space utilization, maintenance more convenient to let customers get the greatest satisfaction .

Specification

Type	Unit	TNC-20H	TNC-26H
Max turning diameter	mm	20	26
Processing length	mm	160	210
Spindle speed	R/min	200~10000	200~10000
Min degree of spindle indexing	/	Stepless	1°
Max. drilling dia.	mm	Ø8	Ø10
Max. tapping dia.	mm	M6/Copper 10	M6/Copper 10
OD tool rest Nos	/	5	5
Axial unspinnable hole cutting tool	/	4+2	4+2
Lateral living rotary tool	/	4	4
Axial living rotary tool	/	2+2	2+2
Back machining tool	/	4	4
Sub-spindle speed	r/min	200~8000	200~8000
Cylindrical turning tool specifications	mm	10×10×120	16x16x120
Min Mechanical resolution	mm	0.001/X1(0.0005)	0.001/X1(0.0005)
Rotary live tool speed	r/min	50~5000	50~5000
Max dia of the rotary tool	mm	Ø10	Ø10
Axial tool specifications	mm	Ø2~Ø10	Ø2~Ø10
Control axis	/	5	5
Cutting speed	mm/min	1~6000	1~6000
Rapid feed rate X1	m/min	20	20
Y1,Z1,X2,Z2	m/min	30	30
The sub-spindle maximum clamping diameter	mm	20	26
Spindle center height	mm	1030	1050
Main motor power	KW	3/3.7	3/5.5
Sub-spindle motor power	KW	3	3
Servo motor power	KW	0.4/0.75	0.75/1.0
power tools power	KW	0.75	0.75
Total power consumption	KVA	15	20
Net weight	Kg	2820	2950
Dimension	mm	200013201700	228013501720

Standard accessories	Special accessories
Explosion-proof work light	Auto bar feeder
Three-color warning light	Conveyer belt of workpiece
Simple feeding mechanism	Fixed floating material device
Auto receiving device
Full-closed protective metal plate
Standard tool 10×10×120
Pull rod of floating tip
Hard alloy collet ¢8
Centralized auto lubrication system
Cooling pump and cooling system
Collet ER11
Collet 1010
Tool box
Pull rod of spindle
