plateform explosion proof lamp
Application:
Applied to oil fields, oil refineries, offshore oil platform, power plants, gas stations, oil tanks, wharf, tunnel, pumping station, substation, the military base,etc. Zone I and Zone ⅡHazardous Locations, Zone 20, Zone 21, Zone 22 and ⅡA, ⅡB, ⅡC explosive gas atmosphere.
Features:
1.Patented design for heat dissipation to ensure life of light source up to 50000 hours.
2.Low power consumption while high light efficiency, power consumption just 20% as much as high pressure sodium lamp, mercury lamp at the same luminous condition, it saves energy more than 75% than that traditional light.
3.Die casting aluminum housing, with anti-static and anti-corrosion coating,high explosion-proof degree of flameproof type; dust-proof, waterproof; lens made of bulletproof PC which is thermal resistance,corrosion resistance, high light transmission.
4.Advanced quadratic light distribution design result in high uniformity of illumination and good lighting quality, clear lighting effect without a double image.
5.Beautiful appearance, several types of installation methods available.
Technical Parameters:
Parameter |
Value |
Power Consumption |
20W/50W/70W |
Input Voltage |
127V AC(applied for 95-265V)/ 24V DC |
Frequency |
50Hz(applied for 47-63 Hz) |
Beam Angle |
60° /90°/120° /140° |
Explosion-proof Grade |
Class 1, Division 2, Groups A, B, C and D |
Corrosion-proof Grade |
WF2 |
IP Grade |
IP67 |
Power Factor |
>0.90 |
Total Harmonic Current |
<20% |
Lamp Efficiency(%) |
≥90% |
Color Temperature(K) |
Warm white:2700-4000K; Pure white: 5000-6500K |
Junction Temperature(TJ)) |
<55°C |
Color Rendering Index(CRI) |
Ra>70 |
Light Effect |
>90lm/W |
Ambient Environment |
Temperature: -30°C—55°C; Humidity: 10-90%RH(25°C) |
Storage Temperature |
-40°C-60°C |
Lifespan |
>50000Hs |
Material |
Aluminum Alloy |
Cable Entry |
Φ8~Φ14mm |
Threaded Fitting |
G3/4" |
Installation Height |
2~4m |
AISI 316 Stainless Steel Enclosure |
Explosion protected stainless steel junction box |
Flameproof stainless steel junction box |
Stainless steel conduit outlet box |
Stainless steel junction box |
Stainless steel cable glands | Brass cable glands | LED Flood lights |
1. Design & Engineering
A.Experienced and skilled team of designers including PROE and CAD designers; 10 years explosion proof products’ experience has the capacity to deliver outstanding designs for your project.
B. Simple design service is free of charge to all clients to ensure customer.
C. We look forward to delivering exceptional designs and advice for your project.
2. How to buy your ideal products?
A. You can provide us your drawings, requirements; and we will produce plateform explosion proof lamp as your drawing. Or we can design as your requirements if you do not have a clear plan.
B. According to products description, choose what you needs; any questions, please contact with us at anytime.
3. How to pay?
A.TT and L/C at sight are acceptable; TT will be more appreciated 30% deposit before producing, 70% balance before loading by TT.
B.Other terms of payment, contact with us, reach an agreement.
4. What is the delivery time?
A. It depends on order quantity.Generally, the delivery time will be within 5 to 10 days.
5. Package information
A.For inner packing and outer box are made as per international standards, and we can make special designed for you if need.
B. If necessary,will be packed in plywood case to avoid any damage and convenient to transport.
6. How long to make a sample?ls it free?
A. 7 DAYS depending on the sample’s complexity.
B. Normally, our sample is free.Pay the charge in advance, after completed 10 PCS(Order quantity depend on the different products.) order, return the sample charge.
7.What’s the shipping documents?
A. Instruction;
B. Factory inspection report;
C. Warranty;
D. Others as your requirements.
