Chinese Herbal Medicine Pulverizer/herbal Medicine Crusher Sale

Chinese Herbal Medicine Pulverizer/herbal Medicine Crusher Sale photo-1
Chinese Herbal Medicine Pulverizer/herbal Medicine Crusher Sale photo-2
Chinese Herbal Medicine Pulverizer/herbal Medicine Crusher Sale photo-3
US$ 500 - 1,600 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Henan, China
Brand Name:
dingli
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao shanghai
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Place of Origin Henan, China
Brand Name dingli
Model Number DL-30
Voltage 220V&380V&others
Power(W) 4KW
Dimension(L*W*H) 730*750*715mm
Weight 60KG
Certification CE&ISO
Warranty 1 year
After-sales Service Provided Engineers available to service machinery overseas

Chinese herbal medicine pulverizer/herbal medicine crusher sale

Chinese herbal medicine pulverizer/herbal medicine crusher sale Introduction:

The machine is equipped cutter, guillotine cutting and grinding on crusher, it not only can be processed dry corn straw, dried sweet potato vine, dry weeds and other dry feed, but also processing fresh corn stalks, fresh sweet potato vine, green weeds, vegetables fresh sweet potato, potato and other fresh wet feed.

Installation and debugging equipment:

(1). The new machine before use, first check to open the cover, the distance between the fixed knife and knife, the distance between the knife with the blade  is 0.2 mm - 0.3 mm at  best.(the knife with adjusting bolt)

(2). Check whether the pressure sieve bottom bolt is loose, and then put down the cover, then hold-down bolts.

(3). The host wheel and momentum wheel profile  must be on a level,  when the belt is putting down, which is not too loose or too tight.

(4). Before starting Chinese herbal medicine pulverizer/herbal medicine crusher sale , turn the pulley by hand,the sound may not appear in the rotating friction and collision , finally open the machine, check the running direction, and then can  put into normal production.

Working principle

In operation, the material to be processed from the hopper into the crushing chamber, hit and break by the high speed rotation of working parts, while changing the direction of movement of the material, as a result of the destruction of high-speed rotating component deposition material layer, therefore, the material with movement of the rotor, in this process, the particles collide repeatedly by working parts and body and collision between particles, friction, thereby gradually grinding to a geometric diameter less than the diameter of the mesh, under the action of centrifugal force and airflow, the material is crushed drain through the sieve into the crushing chamber from the discharge port.

Chinese herbal medicine pulverizer/herbal medicine crusher sale technical parameters:



Model

DL-30

Boundary dimension

(mm)

730*750*715

Speed of mainshaft

(r/min)

4000

Rotor diameter

(mm)

300

Weight(kg)

60

Matched power

(KW)

4

Chinese herbal medicine pulverizer/herbal medicine crusher sale
Chinese herbal medicine pulverizer/herbal medicine crusher sale
Chinese herbal medicine pulverizer/herbal medicine crusher sale
Chinese herbal medicine pulverizer/herbal medicine crusher sale
Chinese herbal medicine pulverizer/herbal medicine crusher sale
Certifications

Official Qualificatons

we have got certification of ISO1400:400 and ISO9001:2008, more than 60 on biomass fuel, 2 research achievement and science & technology award and 1 national innovation funding.



Our service:

1.We are professional manufacturer and have more than 20 years experience as well as engaged in pellet making machine/pulverizer/ granulator

2.we are responsible for users’ site planning, process design, equipment installation and operation training. And our engineer is available to go overseas installpellet making machine/pulverizer/ granulator for you.

3.warranty:one year for drying waste medicine dregs automatic roller dryer equipment, and long-term supply of parts

Company Information

We are Henan Dingli Drying Equipment Co.,Ltd,locate at No.59,Dongda Street,Guancheng

Dist.,Zhengzhou,China.



Crushing devices as crushers/crusher machine/wood crusher machine/sugar cane crusher machine/corn cob crusher machine/leaf crusher machine/crusher and pellet mill all-in-one machine/hammer mill/Horizontal



Your demands about Chinese herbal medicine pulverizer/herbal medicine crusher sale can be fully considered and the equipmentconstructions can be designed. Welcome to contact us or visit our factory.
