mine equipment for drying coal specification price
Mine drying kiln for cooking coal or afghan coal is mainly consists of the heat source, feeding device, belt type feeding port, rotary drum, belt type discharge port, draught fan, deduster and power distribution cabinet.
Main characteristics of mine drying kiln for cooking coal or afghan coal
1. mine drying kiln for cooking coal or afghan coal is of strong overload capacity resistance, large process load, low fuel consumption, and low cost.
2. Adopts direct flow drying method. The gas fume and the material go to the rotary drying equipment from the same side. By using the hyperthermia gas fume, the evaporation strength is very high. With the low outlet temperature, the heat efficiency is very high.
3. The operating parameter of mine drying kiln for cooking coal or afghan coal can be changed according to different materials. So that the material can form a stable fabric curtain and achieve fully heat exchange.
4. The new type feeding and discharging device of rotary drying equipment solve the problem of feeding jam, discontinuous and uneven feeding, and returning charge lighten the load of dedusting system.
5. The new inner structure of rotary drying equipment strengthens the cleaning and heat conduction of the dispersed material, and eliminates the bonding in the inner drum wall. The adaptability to the material moisture and stickiness is stronger.
6. The zero level thrust of the rotary drying equipment reduces the abrasion to the catch wheel and the riding wheel. The operation of the rotary drying equipment is stable and reliable.
7. mine drying kiln for cooking coal or afghan coal adopts the riding wheel device, which keeps the riding wheel and the rolling ring linear touch all the time. Thus the abrasive and the power loss are greatly reduced.
8. Adopt unique coarse coal delay of drying technology, which can guarantee coal slime drying uniformity
mine drying kiln for cooking coal or afghan coal Site and final medium
Specifications of mine drying kiln for cooking coal or afghan coal (we can also made according to your special sizes)
Model |
DL-1.8x20 |
Diameter (M) |
1.8 |
Length (M) |
20 |
Installation obliquity (%) |
3-5% |
Speed (r/min) |
3-6 |
Drying temperature (°c) |
≥800 |
Capacity (t/h) |
5.5 |
Motor (kw) |
18.5 |
Weight (ton) |
33 |
All of mine drying kiln for cooking coal or afghan coal are althorized by government or insitutes.
we are Henan Dingli Drying Equipment Co.,Ltd. We manufacturing various dryes mainly for wet coal/original coal dryer drying equipment construction,lignite drying,sawdust drying, hen dung drying,wood drying,straw drying,sauce drying and many other biomass
dryers.The whole equipment system can include, the pellet machine,particles machine and packing machine,dust removing machine,biomass crusher,wood cutting machine and others. The machine can easilly used as fully automated and semi-automatic in intelligent designs.
Your demands about mine drying kiln for cooking coal or afghan coal can be fully considered. Welcome to contact us or visit our factory.
