scanner for 3d design CE good price
No. |
Title |
Unit |
Quantity |
001 |
White light(Taiwan)DLP |
set |
1 |
002 |
Camera sensor |
piece |
2 |
003 |
12mm Industrial lens |
piece |
2 |
004 |
Visualization ranging system |
piece |
2 |
005 |
Calibration system |
piece |
2 |
006 |
Control software of Scanning measurement |
set |
1 |
007 |
3mm marker |
piece |
20,000.00 |
008 |
Professional Paint |
bottle |
2 |
009 |
Portable suitcase |
piece |
1 |
010 |
Tools |
set |
1 |
011 |
Customized tripod |
set |
1 |
012 |
360°Rotary table |
set |
1 |
Features:
Automatic scan stitching, black or a soft surface also can be scanned;
Point cloud data at 0.05 the following overall accuracy, detail clear lines,
With complete software interface system, including three-dimensional scan / point cloud display a single color / shading / real texture display, zoom display , delete, etc. the point cloud .
Point cloud format ASC,, IGS STL automatically create a triangular face.
Equipment advantages:
Body parts with precision and industrial grade CCD camera, a higher stability of the machine.
Software a healthy operation, faster.
After the factory by the manufacturer before the machine precision calibration for multi
camera , a powerful fully autonomous software system , without third-party software for processing, a machine , the system is equipped with a powerful point cloud removed, smooth, uniform, and automatically generate STL triangles and other treatment feature, you can quickly automate the completion of multiple point cloud processing .
Support ASC, IGES, OBJ, STL, VRML, DXF formats and other data , you can market a variety of CAD, CAM and other design software, docking, long-term upgrades and technical support to ensure the system's long-term upgrade updates and technical support.
Multi- mode scanning
When scanning without manual adjustment, multi- mode state to meet the size of the piece of three-dimensional scan detection
· Portable design:
Hardware system size, small footprint, no noise, easy to dismantle and easy to install, easy to bring to the measurement site
· Scan fast:
≤ 1-4 seconds millions of data points available, high efficiency (the system can also be customized according to customer demand)
High precision:
Using the unique measurement technology, single scan accuracy up to 0.01 ~ 0.03mm (depending on model), photographic measurement accuracy up to ± 0.05mm/4m
· Signs point automatic stitching:
Real-time display automatic stitching scanning process, the scan flips and move the object can be arbitrary. By splicing form of signs point to a three-dimensional object scanning measurement data, enabling full- body scans. Reducing the dead and blind scan measurements.
Three-dimensional surface continuously scan:
Each scan a three-dimensional characteristics of the surface , through a full range of scanning , the data is automatically spliced to obtain three-dimensional data of the entire object surface , high measuring point density and very rules ( in a matrix arrangement )
· Non- contact scanning:
The use of photographic style principle, non- contact 3D optical scanning, and three-dimensional data obtained surface. And adapted to the soft, deformable object measurement requirements
· Scan range:
Scanning range can be selected freely. There are two stand-alone modes without adjustment for different size products
· Large depth of field:
Not only meet the general object scanning, suitable depth scans larger objects
· Noise point cloud processing:
Noise -point automatic pruning, remove
· Broad environmental requirements:
Not much affect the normal environment of the three-dimensional optical scanning system , under normal office environment light can get high-quality 3D data
· Highly intelligent software design:
Accurate registration global error control module automatically deleted coincidence point cloud integration into a single point cloud smoothing
· Measuring the output data interface widely:
The measured point cloud data as ASC, STL, PLY, etc., three-dimensional color data format is VRML (X, Y, Z, R, G, B) format directly with Surface, image ware, UG, CATIA, Geomagic, Pro / E, Master CAM software for data exchange data
· Software compatibility:
Platform compatible Windows98/NT/2000/XP/Vista/Win7
· Operation is simple:
Users to learn and use, without too much training ( 1-2 days ) that can skillfully operate.
