Deep Down Hole Water Inspection Camera Downhole Camera for Sale

Name: Deep Down Hole Water Inspection Camera Downhole Camera for Sale
Brand: Gold
SKU: 121011609
Availability: InStock

Chongqing Huobo Surveying Instruments Co., Ltd.

US$ 0.10 - 0.10 MOQ: 1 Set

Key Specifications

Place of Origin:

Chongqing, China

Brand Name:

Gold

Model Number:

GYGD-II

Payment & Shipping

Payment Methods:

Port of Shipment:

Chongqing

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Chongqing, China

Brand Name Gold

Model Number GYGD-II

Deep Down hole Water Inspection Camera Downhole camera for sale

What is Application of Downhole Camera ?

1.Stratum structure divide

2.Well wall stratum crack

3.Karst development discrimination

4.Distinguish fractured development zone

5.Determine the karst distribution position

6.Long time underground borehole monitoring

What is Feature of Downhole Camera?

1.Real time record

2.High resolution camera

3.Waterproof camera

4.Colorful display screen

5.Widely used in water well, oil field, coal field, engineering geology, dam, reservoir,Oceaneering

What is Specification of Downhole Camera?

No.	Configuration	Dimension	Specification
1	Camera probe	Diameter: 50/80mm Length: 470mm	1. Camera lens are manufactured with high-quality resins. 2. High-quality steel body with solid structure, not easy to be damaged. 3. Maximum bearable pressure: 20Mpa (can reach the depth of 2000m under water) 4. 6-12 LED lamps are available
2	Camera		1. Sony inducer 1/3’’ CCD 2. HD 850 TVL image definition 3. Waterproof 4. Panoramic lens camera
3	Specialized cable	Length: 0-2000m (optional)	1. With steel wire 2. Max bearable tension: 260kg
4	Control unit		1. 220V/380V/12V optional voltage mode 2. Aeronautic aluminium case
5	Downhold pulley		Logging depth counter equiped
6	Logging winch		Manual & electric winch available
7	HD DVR		SD card
