Hi Tagert Qmini MP Field Controller
Technical parameters:
System Configuration
Operating system…………………..……. Windows Mobile 6.5
Processor………………………………………………………….. 806MHz
RAM………………………………………………………..….. 256MB RAM
Flash memory………………………………………………………… 8 GB
Display……………..……… 3.7 inch LED, 640×480 resolution
GPS Features
GPS………………………………………………………………..……….. L1
BDS………………………………………………………………………….. B1
Built-in high sensitivity anti-interference GPS antenna
Update rate……………………….…. 1fix/s (User configurable)
Update rate................................... 1Hz (Configurable w/future FW 2Hz max)
Time to first fix (TTFF)…………………. 35 seconds (Typical)
Position Accuracy
Single point positioning……………………………………..……… 5m
Application Functions
5 million pixel camera with LED
Built-in speaker
Communication Interface
BLUETOOTH 2.1+EDR
Mini USB
WIFI: 802.11b/g
Micro SD card slot, supports up to 32GB
Built-in 3G module
Power Supply
3.7V, 3100mAh lithium battery, up to 8 hours continuous work, online charging
Physical Properties
10 keys, with the four arrow keys
Size……………………..………………. 152mm x 82mm x 32mm
Weight……………………………………………. 315g (with battery)
Operating temperature…………………………..-20℃ to +70℃
Storage temperature……………………………….-30℃ to +80℃
Water/dustproof………….………………………..………………. IP67
Anti-shock………………………………………………….1.5m free fall
Qmini MP ultra-lightweight tray design, operate friendly with a strength approval. It can work as RTK controller by Bluetooth wireless. It is fully compatible with third-party software with OS Microsoft Windows Mobile 6.5 operating system. Built-in professional GPS module achieves the perfect combination of RTK and GIS data collection.
System Features:
l With Microsoft Windows Mobile 6.5 operating system.
l Fully compatible with third-party software such as Carlson SurvCE, MicroSurvey Field Genius, Digiterra Explorer, EsriArcPad, etc.
l Lightweight and anti-drop design, IP67 dust/water protection.
