Help CenterHorizontal Directional Drilling Rig XZ160A for Trenchless Piping Construction
Related Products
-
Portable Hot Sale DTH Drilling Rig DE120 Integrated Rock Drilling MachineNegotiableMOQ: 1 Set -
Portable Underground Drilling RigNegotiableMOQ: 1 Set
-
ZLJ-800 Hydraulic Tunnel Drill Machine 30 Meters Shallow HoleNegotiableMOQ: 1 Set
-
ZDY-1550G Diesel Engine Powerful Underground Tunnel Drilling RigUS$ 1 - 1MOQ: 1 Set
-
Horizontal Drilling Machine, Tunnel Drilling Machine KDy-30HUS$ 1 - 1MOQ: 1 Set
XZ Series Horizontal Directional Drills are mainly used in the trenchless piping construction and replacement of the underground pipe. The XZ Series Horizontal Directional Drills have the advantages of advanced performance, high efficiency and comfortable operation. Many key components adopt international famous products to guarantee the quality. They are the ideal machines for the construction of the water piping, gas piping, electricity, telecommunication, heating system, crude oil industry.
| Model | XZ160A | |
| Engine | shangchai | |
| Rated power | kW | 100 |
| Max.pullback/thrusting | kN | 160/100 |
| Spindle torque(max) | N.m | 5000 |
| Spindle speed | r/min | 0-180 |
| Backreaming diameter | mm | Ø600 |
| Tubing length(single) | m | 3 |
| Tubing diameter | mm | Ø60 |
| Entry angle | ° | |
| Mud flow rate(max) | L/min | 160 |
| Mud pressure (max) | bar | 100 |
| Overall weight | kg | 6100 |
| DIMENSION (LxWxH) | mm | 5700×1820×2400 |
Mobile / Whatsapp: +86-13637882559
1,Are you trading company or manufacturer?
We are absolutely professional manufacturer, and our factory mainly produce water well drilling rig, core drilling rig, piling rig, etc. We provide comprehensive solution to many fields like geological survey, mining industry, electric power etc.
Our products have been exported to more than 50 countries of Asia, South America, Africa, and get a good reputation in the world.
2,Are your products qualified?
Yes, our products all have gained ISO certificate, and we have specialized quality inspection department for checking every machine before leaving our factory.
3,How about your machine quality?
All of our machines hold the ISO, QC certificate, and each set of machine must pass a great number of strict testing in order to offer the best quality to our customers.
4,Do you have after service?
Yes, we have special service team which will offer you professional guidance. If you need, we can send our engineer to your worksite and provid the training for your staff.
5,What about the qaulity warranty?
We offer one-year quality warranty for machines' main body.
6,How long can you deliver the machine?
Generally, we can deliver the machine in 10 days.
