Integration Crawler Down-the-hole Drill CS200EH

Integration Crawler Down-the-hole Drill CS200EH thumbnail-1
Integration Crawler Down-the-hole Drill CS200EH thumbnail-2
Integration Crawler Down-the-hole Drill CS200EH thumbnail-3
Integration Crawler Down-the-hole Drill CS200EH thumbnail-4
Integration Crawler Down-the-hole Drill CS200EH thumbnail-5
Integration Crawler Down-the-hole Drill CS200EH thumbnail-6
Integration Crawler Down-the-hole Drill CS200EH photo-1
Integration Crawler Down-the-hole Drill CS200EH photo-2
Integration Crawler Down-the-hole Drill CS200EH photo-3
Integration Crawler Down-the-hole Drill CS200EH photo-4
Integration Crawler Down-the-hole Drill CS200EH photo-5
Integration Crawler Down-the-hole Drill CS200EH photo-6
US$ 10,000 - 10,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, down the hole
Power Type:
Diesel
Contact Supplier Request Quote Chat Now
Chongqing Huobo Surveying Instruments Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Tianjin Chongqing
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Other, down the hole
Power Type Diesel
Place of Origin China
Brand Name Gold
Model Number CS200EH
Usage Other, Construction
Power(W) 45 KW
Dimension(L*W*H) 12700*3450*5000 mm
Weight 33000KG
Certification CE
Warranty 1 Year
After-sales Service Provided Engineers available to service machinery overseas

FAQ





Product Description



integration crawler down-the-hole drill CS200EHintegration crawler down-the-hole drill CS200EH

Specification



Item Name Specifications Supplier Remarks
1 Structure L×W×H mm 12700×3450×5000   Dry dust collecting outside plug-in type, not included inside
Weight kg 33000
2 Chassis track  assembly PC200-7(lengthening)
Travel motor GM 35L-D-76-140-3
total displacement of Motor(full/half) 140/76
Travel speed 2.0/1.0( Fast/slow block)
Gradeability ≥20°
3 Drilling parameters Drilling diameter  mm 138~202
Drilling depth  m 18m   Can be option
Boom swing angle 0~40°
Drilling angle -15°~+60°   Vertical basis
Swing angle about the propeller ±20°   Advancing with the angle of the vertical line
Drilling rods diameter mm 114   According drilling diameter
Drilling rods length m 9
Drill library drill pipe capacity 1 pieces
4 Compressure parameter Model E1000RH
Sullair

 Add a set of pre-filter
Output pressure  MPa 2.07
Displacement m3/min 28.3
Motor type Y2-355L-4
Power kW 250
5
Power
System

 Engine model 4BTAA B3.9 C115 CUMMINS
Power   kW 86/2200rpm
Max. torque  N.m 447/1500rpm
Motor type Y2-225M-4
Power  kW 45
Hydraulic pump Model A1OV045
Hightech

 Rexroth technology
Displacement ml 45
6
Advance
Parameter

 Advance motor model IY3-1000IZD47+F

YINING

Output torque N.m 2800
Total displacement ml 1078
Propulsion force (lift)
kN
 0~39   Continuously adjustable
Propulsion speed (lift) 0~26m/min   Continuously adjustable
7
Rotation
Parameter

 cycloid Motor Model 604-1384 YIDUN
Displacement  ml 160
Gearbox reduction ratio 4.3
Rotary torque Nm 4700
Working rotation speed rpm 0~44/0~88   Two steps of continuously adjustable
8 American
Box changes		 Rated capacity  kVA 500
Rated input voltage  KV 6
9 Others Impactor RH550   Sandvik
Control type PLC
Electrical system voltage V DC24
Catching dust way Wet type+ dry type   Bring their own water tank, available for the eight-hour work
10 Working condition Maximum altitude m 3000
Ambient temperature -40~50℃
