HZ-130Y Water Well Drill Machine
*Apply for:
1.Geological general investigation and exploration;
2.Base of rod and tall building foundation's exploration;
3.Making checking hole for various concrete structure;
4.Making grout hole or direct grouting for dam and subgrade;
Making well and for earth temperature central air-conditioner use.
*Why choose products of Gold:
1.Our products is cheap and fine,it’s compete in the market;
2.Products are multi-function,it can satisfied customer’s various requirements;
3.We have our own technology support,customer can enjoy better service.
3.Our machine has 1 years warranty;
4.Our machine has certification.
*Detail data of the water well drill machine:
| Main machine | Model | Unit | HZ-130Y |
| Drilling Depth | m | 130 | |
| Max open hole diameter | mm | 260 | |
| End hole diameter | mm | 75 | |
| Drill rod diameter | mm | 50 | |
| Drilling angle | Degree | 90-75 | |
| Drill weight | Kg | 510/560 | |
| dimension | m | 2.5*0.9*1.3 | |
| Spindle | Spindle speed | r/min | 142/285/570 |
| Spindle stroke | mm | 450 | |
| Hoist | Max single line hoisting capacity | Kg | 960 |
| Single line lifting speed | m/s | 0.41/0.82/1.64 | |
| Drul diameter | mm | 140 | |
| Tightrope length | m | 27 | |
| Mud pump | Type of mud pump | Horizontal Single Urn Twin-Action | |
| Diaplacement | L/min | 95 | |
| Max pressure | Mpa | 1.2 | |
| Working pressure | Mpa | 0.7 | |
| Inlet diameter | mm | 30 | |
| Outlet diameter | mm | 20 | |
| Triangle conveyer belt | mm | B1575 | |
| Feature | Normal type Hydraulic water well drilling rig | ||
*Packing and Delivery:
1.Packing
1 PC/CTN package with foam inside and wooden-box outside.
2.Delivery
Delivery time:within 15 days
*Company information:
Chongqing Gold Mechanical & Electrical Equipment Co.,Ltd is a high-tech enterprise for researching,designing,developing and producing oil treatment equipment.With it’s continuous drawing of lessons,unremitting innovation and borrowing of advanced technology form both at home and abroad,our company is now becoming a professional manufacturer of oil purifiers which are excellent in quality,capable of standing wear,complete in various styles.And it’s aviation,ship,railway,pharmacy and edible oil processing.Though highly acclaimed and favorably accepted by numerous customers and possessed of the right to import and export,to ensure the high quality of our products,we conduct our manufacturing in strict accordance with the standard JB/T5285-2001 by Ministry of Machine Building,standard DL/T521-2004 by Ministry of Power Industry.
Our main products range is mechanical and electrical products (compact machinery, concrete machinery, pavement machinery, scraper armed, road machinery, small machinery, hoisting machinery, fire engine, sanitation equipment, pile-driving machinery, bridge inspection car, lorry-amount crane, overhead working truck, mining machinery, aerial work platforms, forklift, car and motorbike etc.)
We have persisted on the business idea of “Integrity Basis and Quality First” for the stable and constant development.We are making effort to develop together with customers from both domestic and abroad on the basis of reciprocity.Client,quality and service are our supreme target.
*Why choose to cooperate with Gold:
1.Our company has rich experiences in this field,we are professional;
2.Our company has own technology term,we nerve stop to produce more convenient and more practical machine;
3.We serve our customers by heart,customers don’t need to worry about quality,delivery and after-sale service.
