Water wells drilling rig
Also used for engineering borehole
Best choice for your projects.
equipo de perforacion de pozos| perforacion de un pozo| brocas para perforar pozos de agua| perforar pozo de agua| perforaciones pozos de agua
Water wells drilling rig GQ-10 is a light mobile water well drilling rig developed by our factory,for the construction of large diameter foundation pile holes. It uses the structure of spindle type core drill, compact structure and small size, light weight, suitable for the construction of skycrapers, dams, harbors, bridges, etc., engineering and other large diameter foundation pile holes drilling.
1.Using the structure of spindle type core drilling rig, has small size, light weight,easy to move,
compare to other engineering construction drilling rigs.
2. The rig has strong intensity,with 6-speed forward,1 -speed reverse, it is suitable to drill for various kinds of earth formation, and easy to handle holes accident happened.
3. The inner diameter of spindle is 96 mm, hydraulic chuck has big clamping force, longer feed
stroke of feed cylinder, the hoist has big lifting force.
4. The rig is lower center of gravity, good stability, long retraction distance, it is suitable for
drilling hole within 1000 mm of diameter.
5. Reasonable arrangement, easy to manipulate, flexible and easy maintenance.
6. Equipped with walking device, easy to align drilling hole.
| unit | Value | ||||
| hole caliber | mm | 400 ~ 1000 | |||
| drilling depth | m | 100 ~ 50 | |||
| Y225M-6 electric motor | forward | r/min | 47.6; 80; 134; 224; 355; 383 | ||
| Spindle speed | reverse | 53 | |||
| Y225S-4 electric motor | forward | 72; 121; 202.5;338; 536; 578.5 | |||
| reverse | 80 | ||||
| Max. spindle output torque | Y225M-6 electric motor | N.m | 6000 | ||
| Y225S-4 electric motor | 4980 | ||||
| spindle push force | kN | 73.5 | |||
| spindle pull force | kN | 98 | |||
| Max. spindle feed stroke | mm | 600 | |||
| lifting force of hoist (with single wire rope) | kN | 39.6 | |||
| retraction distance | mm | 530 | |||
| power unit | Electric | Y225M-6 30 kW 980r/min | |||
| motor | Y225S-4 37 kW 1480r/min | ||||
| overall dimension (L×W×H) | mm | 3030×1250×1935 | |||
| weight (excluding power unit, kelly) | kg | 2200 | |||
| Max. detachable part | kg | 350 | |||
1.Core Drilling Machine 2.Water Well Drilling Machine 3.Anchoring Drilling Rig
4.Down-the-hole Drilling Machine 5.Underground Drilling Rig 6.Horizontal Directional Drilling Rig
