Home > Manufacturing & Processing Machinery > Drilling Rig > Mine Drilling Rig > Efficient Multi-founctional Trailer Type Rotary Drilling Rig

Efficient Multi-founctional Trailer Type Rotary Drilling Rig

Name: Efficient Multi-founctional Trailer Type Rotary Drilling Rig
Brand: GOLD
SKU: 121002603
Availability: InStock

Efficient Multi-founctional Trailer Type Rotary Drilling Rig thumbnail-1

Efficient Multi-founctional Trailer Type Rotary Drilling Rig photo-1

US$ 1 - 2 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Type:

Rotary Drilling Rig

Power Type:

Diesel

Contact Supplier Request Quote Chat Now

Chongqing Huobo Surveying Instruments Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Type Rotary Drilling Rig

Power Type Diesel

Place of Origin Chongqing, China

Brand Name GOLD

Model Number XYX-3

Usage Other, geological exploration

Voltage 380V

Power(W) 38kw

Dimension(L*W*H) 4000*2100*2600mm

Weight 4500KG, 4500kg

Certification ISO

Warranty 1 year

After-sales Service Provided Engineers available to service machinery overseas

Hot sale, efficient trailer-mounted drilling rig for geological prospecting, road and tall building’s foundation exploration, dam grouting hole drilling, etc.

XYX-3

Product Description

1.APPLICATION

XYX-3 drilling rig is mainly used in geological general investigation and exploration, road and tall building foundation exploration ,kinds of hole in concrete structure, river levees, subgrade grouting hole drilling and direct grouting, civil wells and earth temperature central air-conditioner,etc.

2.FEATURES

- Convenient for transport

- Hydraulic oil pressure feed device, high efficiency

- Flexible and reliable

- Diesel engine adopt the electric starter

3.SPECIFICATION

Drilling depth	m		100			250		300	600
Drilling DI	mm		300			200		150	75
Open hole DI	mm		300
End hole DI	mm		75
Drilling rod	mm		Φ60
Drilling angle			90°-65°
Rotary Spindle forward
				Spindle speed &nbs="center">r/min			30-1050
Spindle reverse speed				r/min			29-137
Spindle stroke				mm			560
Spindle inner diameter				mm			96
Spindle lifting capacity				KN			60
Main Winch ( drive hydraulic system)
Single line lifting speed					m/min		0-45
Hug floodgate belt width					mm		90
Tightrope diameter					mm		14
Hoist single line lifting capacity					KN		40
Roller diameter					mm		200
Roller cubic measure					m		30
Gear Oil pump
Duplex gear oil pump CBF-F63/25
Front displacement,pressure							63mL/r 20Mpa
Behind displacement,pressure							25mL/r 20Mpa
Drilling rig Power
Diesel engine		Hp					R4105ZD 50HP
Electric motor		KW					Y180L-4 22KW
