KDY-30 Hydraulic Tunnel Drilling Rig

KDY-30 Hydraulic Tunnel Drilling Rig thumbnail-1
KDY-30 Hydraulic Tunnel Drilling Rig photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Core Drilling Rig
Power Type:
Electric
Contact Supplier Request Quote Chat Now
Chongqing Huobo Surveying Instruments Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Core Drilling Rig
Power Type Electric
Place of Origin Chongqing, China
Brand Name GOLD
Model Number KDY-30
Usage Other, tunnel of hydro-power station
Voltage 380V
Power(W) 11kW
Weight 360kg
Certification ISO9001-2000
Warranty 12 months
After-sales Service Provided Engineers available to service machinery overseas



Product Description



 APPLICATIONS:



KDY-30 drill rig is developed faced drilling grouting hole in the tunnel of hydro-power station. It also can be used for drilling hole of support, penetration-proof, blasting for rail way and high way, and treatment of dangerous rock, hillside. It is suitable for hard rock drilling with DTH.




FEATURES



  MAIN FEATURES:



  • Reasonable specifications, assure more efficiently drilling;
  • Fully hydraulic drive, top-head rotation, feed and hoisting are done by ration pump and ration motor which composite independent open hydraulic system, it is simple, advance, easy to use and maintain;
  • The hydraulic components are from world famous hydraulic manufacturers, two-step filtering, to assure the reliability of the hydraulic system;
  • New art design, reasonable arrangement;
  • Light weight, easy to move, re-assembly and maintain, especially suitable for using for tunnel and frame.



specifications



Drilling method:
DTH drilling
Drilling depth:
hole dia.: Φ75 mm        depth: 30 m
hole dia.:Φ91 mm         depth: 20 m
Drill rod:
Φ42 x 1000 mm rod or Φ50 x 1000 mm
Mast height:
2270 mm
Stroke:
1400 mm
Speed:
38~53 r/min
Max. torque:
700 Nm
Max. push/pull force:
12000N
Feed and hoist speed:
0 – 0.254 m/s
Hydraulic system:
twin-gear pump, ration motor Rated pressure: 20 Mpa
Power unit:
electric motor Y160M-4 (speed: 1470 r/min; power: 11 kW)
Detachment weight:
mast: 75 kg, top-drive head: 35 kg,
control panel: 40 kg, wheeled power station: 210 kg





Packaging & Shipping



Package: Wooden Case or Plywood

Shipping: within 10 working days after receival of deposit



Our Services

     Engineers available for overseas service of the machinery



Company Information

   Established in 2009.Chongqing Gold Mechanical & Electrical Equipment Co,. Ltd is a high-tech enterprise specializing in R&D design, manufacture and sale of geological instruments, oil instruments and other precise instruments and equipments.
