2014 Hot cheapest GX-50 bore well drilling machine for railroad, highway, bridge tunnel,
foundations of power station, Civil and industrial buildings, also drilling anchoring hole and
blasting hole etc.
1. Spindle type mechanical transmission, hydraulic feed.
2. Hydraulic retracting lets drill body away from the drilling hole.
3. Hydraulic chuck, hand-powered chuck and hand-powered cylinder chuck, they are exchangeable.
4. Friction hoist,percussion drilling, easy to pull and push casing if equipped with vibrator.
5. Advanced design, reasonable arrangement, compact structure, beautiful looking.
6. Light weight, good detachability, easy to operate.
7. Equipped with special 6mA type derrick for user ordering.
final hole dia (mm) |
150;130;110;91;75 |
|
drilling capacity (m) |
20;30;50;70;100 |
|
angle range |
0-90° |
|
spindle speeds (r/min) |
99;236;378 |
|
max torque (Nm) |
620 |
|
spindle max pull force (KN) |
15 |
|
spindle stroke (mm) |
400 |
|
max hoist lift force with single rope (KN) |
10 |
|
Oil pump |
CB3-10-CFPL gear oil pump |
|
Power unit |
diesel engine |
Changchai diesel S1100 11KW |
electric motor |
Y130M-4;1440r/min 7.5KW |
|
drill body weight(Excluding power) |
360 |
|
overal dim (L×W×H)(mm) |
1360×620×1080 |
|
Package: Wooden Case or Plywood
Shipping: within 10 working days after receival of deposit
Engineers available for overseas service of the machinery
Established in 2009.Chongqing Gold Mechanical & Electrical Equipment Co,. Ltd is a high-tech enterprise specializing in R&D design, manufacture and sale of geological instruments, oil instruments and other precise instruments and equipments.
