Multi-function XY-1000 Core Drilling Rig

Multi-function XY-1000 Core Drilling Rig thumbnail-1
Multi-function XY-1000 Core Drilling Rig photo-1
US$ 1 - 18,888 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Core Drilling Rig
Power Type:
Other, Diesel and electric
Contact Supplier Request Quote Chat Now
Chongqing Huobo Surveying Instruments Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Core Drilling Rig
Power Type Other, Diesel and electric
Place of Origin Chongqing, China
Brand Name GOLD
Model Number XY-1000
Usage Other, drilling large dia hole
Voltage 380V
Power(W) 42kw
Dimension(L*W*H) 2920mm,1100mm,1840mm
Weight 2180kg
Certification ISO9001:2000
Warranty 12 months
After-sales Service Provided Engineers available to service machinery overseas



Product Description





XY-1000 Used Core Drilling Rig of spindle type is brand new products which is developed and designed newly based on current thousand meters sereies of drilling machine.





drilling large dia,hole and small dia,hole core drilling with diamond bit and carbide bit;







engineering geology drilling,hydrogeology drilling,water well drilling and large dia,pile hole drilling.



  • reasonable arrangement
  • good qualityand light weight
  • big capability and wide performance
  • good exchangeability



specifications



Drilling depth (m)

1000

Spindle speed

 forward

87; 160; 230; 270; 334; 500; 710; 1030

 reverse

72; 220

Max.toque of spindle (Nm)

4050

Spindle stroke (mm)

600

Spindle inner dia. (mm)

96

Spindle pull/push force(kg)

10000/7500

Hoist max. lifting force with single rope(kg)

4500

Hoist lift speed with single rope (the third layer)(m/s)

0.69; 1.27; 1.81; 2.64

Hoist wire rope dia. and capacity (m)

17.5(170kg/cm2)  17.5(170kg/cm2)wire rope capacity 110 m

18.5(170kg/cm2) 18.5(170kg/cm2)wire rope capacity 90 m

 Workable speed of water brake (r/min)

700- 1800

Balance speed of water brake(single rope)/balance load(single rope)

3-8m/s/45kN

 Hydraulic system

(32+12)L/min: 80kg/cm2
(32+12)L/min twin-gear pump,pressure:80kg/cm2

 Driving stem

89×79×6000 mm
Hexagonal kelly 89×79×6000 mm

Power unit

 Electric motor

Y225-4 37Kw 1480r/min

 Diesel engine

R4105G54 42Kw 1500r/min

Weight (excluding power unit)(kg)

2180

Max. detachable subassembly (kg)

320

Overal dimesion (L×W×H)(mm)

2920×1100×1840







Packaging & Shipping



Package: Wooden Case or Plywood

Shipping: within 10 working days after receival of deposit



Our Services

   Engineers available for overseas service of the machinery



Company Information

  Established in 2009.Chongqing Gold Mechanical & Electrical Equipment Co,. Ltd is a high-tech enterprise specializing in R&D design, manufacture and sale of geological instruments, oil instruments and other precise instruments and equipments.
