GD100 trailer type hydraulic small water well drilling machine is a efficient, energy-saving and simple structure DTH drilling equipment, main used in drilling water well, monitoring well, geothermal well, agricultural irrigation well, grouting holes of seepage treatment for dam and foundation reinforcement, open mining, and anchoring projects.
This drilling rig can drill with casing, effective solve the technology problem of drilling hole in loose layer.
Drilling depth |
m |
120 |
Drilling diameter |
mm |
115 - 254 |
Rotary speed |
rpm |
38 - 75 |
Rotary torque |
N.m |
3500 |
Feeding force |
kN |
27 |
Lifting force |
kN |
40 |
Working air pressure |
Mpa |
1.05 - 2.46 |
Air consumption |
|
16 - 30 |
Drilling rod length |
mm |
1500 |
Drilling rod diameter |
mm |
Φ76, Φ89, Φ102 |
Engine |
|
YN27 |
Engine power |
Kw |
37 |
Engine speed |
rpm |
2400 |
Ground clearance |
mm |
250 |
Climbing capacity |
|
20 |
Moving speed |
km/h |
2 |
Weight |
Kg |
1800 |
Dimension |
mm |
3000*1200*2000 |
