Hot!! 200m Borehole Drilling Equipment For Sale-South Africa

Hot!! 200m Borehole Drilling Equipment For Sale-South Africa photo-1
Hot!! 200m Borehole Drilling Equipment For Sale-South Africa photo-2
Hot!! 200m Borehole Drilling Equipment For Sale-South Africa photo-3
Hot!! 200m Borehole Drilling Equipment For Sale-South Africa photo-4
Hot!! 200m Borehole Drilling Equipment For Sale-South Africa photo-5
Hot!! 200m Borehole Drilling Equipment For Sale-South Africa photo-6
US$ 1 - 2 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, Borehole Drilling Equipment For Sale-South Africa
Power Type:
Diesel
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Type Other, Borehole Drilling Equipment For Sale-South Africa
Power Type Diesel
Place of Origin Chongqing, China
Brand Name Gold
Model Number HZ-200YY
Usage Water Well
Voltage 380V
Power(W) 14.7kw
Dimension(L*W*H) 2700*900*1500mm
Weight 975kg without power
Certification ISO9001, CE, SGI
Warranty One Year
After-sales Service Provided Engineers available to service machinery overseas
Why choose us

Chongqing Gold Mechanical & Electrical Equipment Co.,Ltd, a professional manufacturer with 15 years experience, specializing in geological equipments and related engineering drilling rigs.

We won our excellent reputation from our customers with our competitive offer and trustworthy quality. Our main target markets focus on Africa, Central and Southeast Asia, South America, especially for their water well drilling construction and geological investigation. We have an professional team for overseas technical after sales service since 2003, having achieved satisfying praise from our customers.

Looking forward to our cooperation, and we will do our best to satisfy you in 2016!

Product description

HZ-200YY Spindle Drilling Machine is mainly used for geological general investigation and exploration, road and tall buliding foundation exploration, kinds of hole in concrete structure, river levees, subgrade grouting hole ,drilling and driect grouting, civil wells and earth temperature central air-conditioner,etc.

Drilling depth
200m
Max open hole caliber
300mm
End hole caliber
75mm
Drill rod caliber
60mm
Drilling angle
90°~75°
Drill weight (without power)
975kg
Triangle conveyer belt
B950 x 4 B1700 x 3
The main machine moving distance
300mm
Power
Diesel engine 22HP Electric motor 15kw
Spindle
Spindle speed
64, 128, 287, 557r/min
Spindle stroke
450mm
Hoist
Max.lifting capacity
2400kg
Single line lifting speed
0.41, 0.82, 1.64m/s
Wirerope caliber
13mm
Wirerope length
35m
Reel diameter
140mm
Hug floodgate caliber
260mm
Hug folldgate belt width
70mm
Mud pump
Type
Horizontal single-urn twin-action
Displacement
Diesel engine 170L/min Electric motor 150L/min
Maximum pressure
3Mpa
Work pressure
1.5Mpa
Inlet pipe caliber
40mm
Outlet pipe caliber
30mm
Triangle conveyer belt
B1728mm
Hydralic oil pump
Type
CBT-F-314
Triangle conveyer belt
B1100 X 1
Hot sale models

XY-8 Max 3000m Core sampling drilling rig, multipurpose use

Multi-functional geological investigation drilling machine, with BQ, NQ, HQ wireline coring methods.

HZ-200YY common 200m drilling rig for water well sites

Widely used in most well drilling on general soil formation. Trailer/Crawler can be mounted for easier operation.

Aluminium alloy, high strength, easy carry XY-3T drilling rig

All aluminium material equipped drilling machine, light carry and easy move with less than 3 drillers.

MDL-150 full hydraulic, multipurpose anchoring rig

Multi-functional, 130-170m depth all hydraulic drilling operations.

JDL-300 Crawler type mud/air down the hole drilling rig

Mechanical & Hydraulic transmission for mountainous and rocky formation, max to 300m depth.

XYC-3 Max 600m fast move truck mounted drilling rig

High efficient movement for water well drilling and other operations.
