Competitive Geotechnical Hydraulic Mine Drilling, Mining Rig

Chongqing Gold Mechanical & Electrical Equipment Co.,Ltd, a professional manufacturer with 15 years experience, specializing in geological equipments and related engineering drilling rigs.

We won our excellent reputation from our customers with our competitive offer and trustworthy quality. Our main target markets focus on Africa, Central and Southeast Asia, South America, especially for their water well drilling construction and geological investigation. We have an professional team for overseas technical after sales service since 2003, having achieved satisfying praise from our customers.

Looking forward to our cooperation, and we will do our best to satisfy you in 2016!

 XY-8 Features:

Machine adopts pneumatic shift Fastgear 8JS118 auto transmission and clutch, compact structure, smooth operation, stable performance, good wildcard.

Using auto-control flexible-shaft shift agency, we achieve the long-distance transmission shift. The pneumatic shift is light and agile, and has the advantage of hommization.

Reasonable speed range and many speed radixes (8 forward speed, 1 reverse speed), with low-speed it has big torque (Max. up to 8000N.m).

Using concentrated forced lubrication system, as long as the rig runs, the separate lubrication oil pump starts working and sends lubrication oil to each node that requires lubrication. When the oil lubricates drive mechanism, it will also take away the heat inside, (lubrication system with separate condenser), to prevent the components from heat caused by high-speed high-load state.

The rig adopts involute splined vertical shaft instead of the traditional hexagonal vertical shaft, exponentially increasing gyrator transmission efficiency and carrying capacity. And new spindle shaft has big hole diameter (96 mm), with twin cylinder hydraulic feed the trip is

much longer (up to 1000mm), especially suitable for large diameter drill pipe wireline coring, help to improve drilling efficiency and reduce the hole accident.

Light weight and can be disassembled to many parts, net weight 6500Kg.
