HGY-300 well water drill rig :
Features of well water drill rig HGY-300 :
1) Good stability and high reliability.
2) Multilevel positive and reverse rotate speed.
3) The complete hydraulic chuck and vertical spindle.
4) Convenient to transport with the small volume and light weight.
5 )Perfect frame's rigidity ,low center of gravity and good stability.
Applications of well water drill rig HGY-300 :
1.Construction drilling of the projects e.g. prospection, railway, road, port, bridge, water conservancy and hydropower, tunnel, well, industrial and civil construction
2. Coal mining exploration, Ore exploration
3. Small hole diameter water well drilling
4. Geothermal pipe-installing for heat pump
5. Small-diameter hole foundation piling drilling;
Technological Data of well water drill rig HGY-300 :
| Type | HGY-300 |
| Drilling depth(m) | 300 |
| Drilling rod diameter(mm) | 50 |
| Head angle range | 0~360° |
| Cylinder stroke (mm) | 400 |
| Spindle speed(r/min) |
Positive rotation rate:34 67 115 189 238 156 307 531 868 1094 Reverse rotation rate:38 173 |
| spindle hole diameter (mm) | 65/96 |
| Spindle output torque (N.M) | 3100 |
| Spindle stroke (mm) | 530 |
| Spindle driving force max. (KN) | 40 |
| Spindle lifting power max. (KN) | 60 |
| Lifting speed (m/s) | 0.30 0.59 1.01 1.66 2.09 |
| Single rope lifting power (KN) | 30 |
| Steel wire rope diameter (mm) | 13 |
| Mode of chuck | Full Hydraulic chuck |
| Weight (power unit excepted)(kg) | 1200 |
| (L*W*H)(mm) | 2000×900×1600 |
| Diesel engine | 495D(26.5KW) |
| Electromotor | Y180L-4(22KW) |
For water well, you also need drill tools as flow:
Brief introduction :
1.50 years professional manufacture
2. Certificate: ISO9001:2000 and ISO9001:2008
3. Export to: Africa, the Middle East, South America, Asia,
Countries: South Africa, Zambia, Sudan, Iran, South Korea, Costa Rica etc.
| |||
| Our factory | our team of foreign trade | In 1992, 100m drill in Antarctica in the world | Go to drilling site to train drilling knowledge |
|
|
|
|
| Max. Depth:1000m | Max. Depth:1500m | Max. Depth:200m | Max. Depth:100m |
How to install this rig? How to operate this rig?
Don't worry, buy our products, we will give you professional guidance.
We have produced drilling equipments for more than 50 years.
We are a Professional manufacturer.
If this rig is right for you,don't hesitate to contact us immediately.
If not, it does't matter, email to us and tell us which rig do you want, we will reply to you immediately respond to you and recommended right drilling rig for you.
Don't hesitate, email to us now. You will get unexpected results !
