PRICE water well drilling rig, Water well drilling rig manufacturer
- 60 Set / Sets per Month
- Changsha/Shanghai/Guangzhou
- T/T
-
China Xy-200 Water Well Drill Rig Machine for Soil and Rock Drilling
-
100 Meters Xy-1A Water Well Drilling Rig Machine Equipment
-
HY-50H Small Domestic Hydraulic Water Well Drilling Rig of China
-
50m Depth Core Drilling Rig Portable Diamond in Mountain
-
TSP core bit, BQ NQ HQ PQ core drill bits, HWL, wireline core barrels, diamond coring bits, hard formation, deep hole rock core recovery
-
1.5M 3M inner tube assembly, wireline core barrels, head assembly, impregnated diamond drilling, hard formation coring, deep hole rock core recovery
Product Details
| Condition: | New | Type: | Other, Rotary Drilling Rig, small, spindle, mini, deep, XUL-100, 100m | Power Type: | Diesel |
| Place of Origin: | Hunan, China | Brand Name: | FLYDISC | Model Number: | XUL-100 |
| Usage: | Water Well | Voltage: | 220V | Power(W): | 12 |
| Dimension(L*W*H): | 1200*650*1300 | Weight: | 550 | Certification: | CE/ISO9001: 2008 |
| Warranty: | 6 months | After-sales Service Provided: | Overseas service center available |
Product Description
XUL-100 water well drilling rig manufacturer
Historical view of water well drilling rig manufacturer
1) 1992 the first drill rig for the sample boring from the deep stratum of antarctica in the world used by the Chinese Academy of science.
2) Best Quality Awards belonging to China National Nuclear Ministry Hunan province.
Drilling Ability of XUL-100 water well drilling rig
Drilling depth :100m
Drilling diameter: 75mm(46~200mm)
Features of XUL-100 water well drilling rig
1) Advanced capability and high reliability.
2) Excellent design and easy operation.
3) Alternative-designed unit constructions.
4) Accessories in common use.
Technological Data of mini drilling rig water from china : XUL-100
Model | Diamond Core Drilling Rig(XUL-100) |
Drilling depth( m) | 100 |
Drilling rod diameter.(mm) | Φ42 |
Head angle range | 360 |
Movable cylinder stroke (mm) | 300 |
Spindle speed( r/min) | 144 264 590 1083 |
Spindle hole diameter( mm) | Φ54 |
Spindle output torque max(N.M) | 800 |
Spindle stroke(mm) | 370 |
Lifting power max( KN) | 30 |
Driving force max(KN) | 23 |
Lifting speed( m/s) | 0.36 0.7 1.49 2.9 |
Lifting capacity(single) max(KN) | 10 |
Steel wire rope diameter (mm) | 11 |
Mode of chuck | Hand lever chuck |
Weight(power unit excepted)(Kg) | 550 |
Overall dimensions(mm) | 1200*650*1300 |
Diesel engine model | Zs1100 ( 12.1KW) |
Electromotor model | Y160M-4 ( 11KW) |
Application of XUL-100 water well drilling rig :
1.Construction drilling of the projects e.g. prospection, geotechnical investigation, railway, road, port, bridge, water conservancy and hydropower, tunnel, well, industrial and civil construction;
2. Coal mining exploration, Ore exploration;
3. Small hole diameter water well drilling;
4. Geothermal pipe-installing for heat pump;
5. Small-diameter hole foundation piling drilling
The drill tools for water well
Our company has produced drilling equipments for 50 years. We have passed ISO9001:2008, TS16949, CE Certification, MA Certification, High-tech Enterprise Certification.
The rigs are widely used in the construction of the projects e. g. prospecting, railway, road, port, bridge, water conservancy and hydropower, tunnel, well, industrial and civil construction, geological exploration, large diameter boring pile and small diameter diamond core deep hole drilling, etc. The main products are engineering geological drilling rig;water well drilling rig; vertical shaft 100, 200, 300, 650, 1000, 1500m rigs, full hydraulic power head 1000, 2000m rigs. At the same time, we produce drill bits and drill tools matching with the drilling rigs. Many rigs and drill bits possess patent certificates. Our products have exported to many countries of world. Such as Nepal, India, SriLanka, Afghanistan, Malaysia, Iran, Sudan, Chile etc.
| | | |
How to install this rig? How to operate this rig?
Don't worry, buy our products, we will give you professional guidance.
We have produced drilling equipments for more than 50 years.
We are a Professional manufacturer.
If this rig is right for you,don't hesitate to contact us immediately.
If not, it does't matter, email to us and tell us which rig do you want, we will reply to you immediately respond to you and recommended right drilling rig for you.
Don't hesitate, email to us now. You will get unexpected results !
