Core Drilling Machine for Deep Hole Drilling 1500m

Specifications

Core Drilling Machinet for Deep Hole Drilling
1.Core Drilling Rig
2.drill depth:1500m
3.drill Utility patent
4.mining drill

 Core Drilling Machine for Deep Hole Drilling 1500m



Brief introduction of Core Drilling Rig(HGY-1500T):

1.32 years professional manufacture

2. Certificate: ISO9001:2008

3. Export to:  Africa, the Middle East, South America, Asia,

                     Countries: South Africa, Zambia, Sudan, Iran, South Korea, Costa Rica etc.



Features of   Core Drilling Machine for Deep Hole Drilling 1500m ):

1) Wide range of suitable rotary speed to meet various needs.

2) Adopted from the 'jiefang"CA151 auto parts, such as clutch and gear-Box.

3) Reasonable design of the transmission and shift on the principle of bevel gear.

4) A good grip with the disk spring on the Chuck.

5) Convenient to lift up and down the tower, all the work are performed by the hydraulic system.



Use of  Core Drilling Machine for Deep Hole Drilling 1500m :

for geotechnical investigation, exploring, prospecting, water well drilling;

Widely used in the construction of the projects e.g. prospection, railway, road, port, bridge, water conservancy and hydropower, tunnel, well, industrial and civil construction, geological exploring, large diameter boring pile and small diameter diamond core deep hole drilling, etc.



Technological Data of   Core Drilling Machine for Deep Hole Drilling 1500m

Model	HGY-1500T Core Drilling Rig
Drilling depth( m)	1500~1200
Rod diameter( mm)	Φ42~Φ50
Spindle speed( r/min)	Positive rotation rate: 54 86 145 219 310 378 415 570 808 1081 Reverse rotation rate: 58 152
Spindle stroke(mm)	600
Lifting power max( KN)	80
Driving force max(KN)	60
Spindle output torque max(N.M)	7150
Spindle hole diameter( mm)	Φ95
Cable diameter(mm)	17.5
Drum circumferential velocity( 9 layers)	130
Lifting speed( m/s)	0.51 0.81 1.37 2.06 2.92 3.91
Lifting capacity(single) max(KN)	40
Movable cylinder stroke (mm)	400
Gear oil pump model	2CB-FA32/10-FL
Nominal displacement( ml/r)	40
Nominal pressure( MPa)	14
Electromotor model	Y225S-­4 or Y225M-4
Power( kw)	37 or 45
Speed( r/min)	1480
Diesel engine model	R4105ZD1
Power( kw)	56
Speed( r/min)	2800
Diesel engine weght(Kg)	385
Overall dimensions(mm)	2460*1150*1888
Weight(power unit excepted)(Kg)	4100
Head angle range	0~90
Tower load(t)	10
Tower height(m)	9.5
Tower pedestal(m)	4*4.5
