0.10mm-0.50mm thickness pvdf coating aluminum coil color coated aluminum
1. Grade
1) Series: 1060 1100 etc.
2) Series: 3003 3004 3005 etc.
3) Series: 8011 etc.
2. Thickness: Roll Coating: 0.05-3.0mm
Plate Coating: up to 10mm
3. Width: 20mm - 1600mm
4. Temper: H16, H18, H24, H26, H28
5. Inner diameter : 405mm/505mm
6. Standard outer diameter: 1100mm
7. Color: Metallic, Solid, RAL or by customer requirements.
8. Coating paint: PVDF(Polyvinylidene Fluoride), PE(Polyester)
9. Coating thickness: as per customer’s request
10. Protective film: PVC film, Colorless transparent or White-black
Specification:
Product |
pvdf coating aluminum coil |
Alloy |
1060, 1100, 3003, 8011, etc. |
Temper |
H16, H18, H24, H26, H28 |
Thickness |
From 0.05mm to 3.0mm |
Width |
Standard width:1240mm |
Special width:1300mm, 1520mm, 1570mm, 1595mm | |
Diameter |
Standard dia:1200mm |
Interior dia:150mm,405mm,505mm | |
Weight |
2.5 T/coil,3.0 T/coil |
Coating |
PE, PVDF, ACRYLIC |
Surface |
Embossed, mill finish, coated |
Color |
AS to code RAL |
Gloss |
10-90%(EN ISO-2813:1994) |
Coating Thickness |
PE:more than 18 micron |
PVDF:more than 25 micron | |
Coating Hardness(pencil resistance) |
More than 2h |
Coating adhesion |
5J(EN ISO-2409:1994) |
Impact Resistance |
No peeling or cracking(50 kg/cm,ASTMD-2794:1993) |
Flexibility(T-bend) |
2T |
MEK resistance |
More than 100 |
Advantage |
1.High temperature resistant 2.Weathering resistant 3.Scrubbing resistant 5.Acid or alkali proof 6. Fireproof 7.Light weight material is easy to construct and install |
Out package |
Wooden splint with export standard |
Manufacturing:
Decoiler → Accumulator→Tension Leveller →Acid & Alkali Cleaner → Rinse →Conversion Treatment →
Priming coater →Infrared Curing Oven →Main coater →Floatation Curing Oven →Strippable Film Applicator → Exit Accumulator → Recoiler
Application:
1. Exterior applications: wall cladding, facades, roofs and canopies, tunnels, column covers or renovations
2. Interior applications: wall cladding, ceilings, bathrooms, kitchens and balconies
3. Advertisement and market applications: display platforms, signboards, fascia and shop fronts
Kinds of other types and serieses of Aluminum products for choice. Any needs or
interests, welcome your inquiry, pleased to help!!!
Q: How to contact your company?
A: With TradeManager or Skype or Email or the other ways we have written upon.
Q: Can you give us a quotation right now?
A: Please give us detailed technical data. Then we will make a design and quotation for you as soon as
possible.
Q: What is the MOQ (Minimum Order Quantity)?
A: 1 ton
Q: Do you provide your products catalogue?
A: Of course, I will send it to your E-mail if it's convenient to you.
Q: What are your payment terms?
A: We accept L/C, D/A, D/P, T/T, Western Union, MoneyGram etc.
Q: Do you supply other products?
A: Yes, our main products include Aluminum Sheet, Aluminum Coil, Color Aluminum, Mirror Aluminum,
Embossed Aluminum, and Aluminum Foil, Aluminum Circle, Aluminum Tube etc.
At the same time, different dimension can be customized .Welcome your inquiry.
